Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-EC98P
6161
R836 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R837 1-216-845-11 METAL CHIP 100K 5% 1/10W
R838 1-216-837-11 METAL CHIP 22K 5% 1/10W
R839 1-216-797-11 METAL CHIP 10 5% 1/10W
R840 1-216-864-11 SHORT CHIP 0
R841 1-216-833-11 METAL CHIP 10K 5% 1/10W
R842 1-216-864-11 SHORT CHIP 0
R843 1-216-845-11 METAL CHIP 100K 5% 1/10W
R844 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R845 1-216-864-11 SHORT CHIP 0
R846 1-216-797-11 METAL CHIP 10 5% 1/10W
R847 1-216-864-11 SHORT CHIP 0
< RELAY >
RY601 1-755-307-21 RELAY
RY602 1-755-307-21 RELAY
RY701 1-755-307-21 RELAY
< TRANSFORMER >
T801 1-433-741-11 TRANSFORMER, IF
< TERMINAL >
TB601 1-780-381-11 TERMINAL BOARD, PUSH (ANTENNA) 4P
(SPEAKER HIGH FREQ. IMPEDANCE USE 8Ω)
TB602 1-536-708-81 TERMINAL BOARD, PUSH (4P)
(SPEAKER LOW FREQ. IMPEDANCE USE 8Ω)
TB603 1-780-600-11 TERMINAL BOARD (SPEAKER) 1P
(SUBWOOFER IMPEDANCE: USE 4Ω)
< VIBRATOR >
X801 1-813-917-11 VIBRATOR, CRYSTAL (75MHz)
************************************************************
MOTOR BOARD (US, CND)
*************
< CONNECTOR >
CN001 1-779-542-21 CONNECTOR, FFC (LIF (NON-ZIF)) 5P
< SWITCH >
S001 1-786-514-21 SWITCH, LEVER (SLIDE)
(DISC TRAY OPEN/CLOSE DETECT)
************************************************************
A-1379-636-A PANEL BOARD, COMPLETE (US, CND)
A-1426-098-A PANEL BOARD, COMPLETE (AUS)
**********************
2-649-178-01 PLATE, LIGHT GUIDE
2-649-179-01 SHEET (LCD)
2-665-175-01 SHEET (REFLECTOR)
< CAPACITOR >
C301 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C302 1-126-964-11 ELECT 10uF 20% 50V
C303 1-126-964-11 ELECT 10uF 20% 50V
C304 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C305 1-126-964-11 ELECT 10uF 20% 50V
C306 1-104-655-91 ELECT 470uF 20% 6.3V
C308 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V (AUS)
C309 1-126-965-91 ELECT 22uF 20% 50V (AUS)
C310 1-164-156-11 CERAMIC CHIP 0.1uF 25V (AUS)
C311 1-164-156-11 CERAMIC CHIP 0.1uF 25V (AUS)
C312 1-164-156-11 CERAMIC CHIP 0.1uF 25V (AUS)
C313 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C314 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C315 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C316 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C317 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C319 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
C320 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C321 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C328 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C330 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C332 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C338 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C340 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C341 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C342 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C343 1-126-965-91 ELECT 22uF 20% 50V (AUS)
C344 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V (AUS)
C345 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V (AUS)
C346 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C347 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C348 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C351 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(US, CND)
C352 1-126-964-11 ELECT 10uF 20% 50V
(US, CND)
C353 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(US, CND)
C354 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C355 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C356 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C357 1-126-965-91 ELECT 22uF 20% 50V
(US, CND)
< CONNECTOR >
CN301 1-784-753-11 CONNECTOR, FFC 31P
CN302 1-784-735-11 CONNECTOR, FFC 13P (AUS)
CN303 1-815-550-11 PIN, CONNECTOR (PWB) 2P
CN305 1-815-444-11 PIN, CONNECTOR (PWB) 3P
CN311 1-779-273-11 CONNECTOR, FFC (LIF (NON-ZIF)) 5P (US, CND)
< DIODE >
D301 6-501-722-01 DIODE MAZ8043GMLS0
D302 6-501-817-01 DIODE MA2J1110GLS0
D303 6-500-334-01 DIODE MC2836-T112-1
D304 6-501-817-01 DIODE MA2J1110GLS0
D305 6-501-817-01 DIODE MA2J1110GLS0 (AUS)
D306 8-719-063-79 DIODE 1N4002B (US, CND)
D307 6-501-817-01 DIODE MA2J1110GLS0 (US, CND)
< FERRITE BEAD >
FB301 1-500-329-21 INDUCTOR, FERRITE BEAD
< IC >
IC301 A-1551-183-A IC MB90F831PF-G-SPE1 (for SERVICE) (AUS)
IC301 A-1551-185-A IC MB90F831PF-G-SPE1 (for SERVICE)
(US, CND)
IC302 6-711-556-01 IC NJL24H400B-SA
IC303 8-759-598-69 IC BA6956AN (US, CND)
PANELMAIN MOTOR
