Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
45
HCD-EH10
R750 1-216-821-11 METAL CHIP 1K 5% 1/10W
R751 1-216-845-11 METAL CHIP 100K 5% 1/10W
R753 1-216-809-11 METAL CHIP 100 5% 1/10W
R754 1-216-833-11 METAL CHIP 10K 5% 1/10W
R755 1-216-864-11 SHORT CHIP 0
R756 1-216-821-11 METAL CHIP 1K 5% 1/10W
R757 1-216-845-11 METAL CHIP 100K 5% 1/10W
R758 1-216-821-11 METAL CHIP 1K 5% 1/10W
R759 1-216-809-11 METAL CHIP 100 5% 1/10W
R760 1-216-845-11 METAL CHIP 100K 5% 1/10W
R761 1-216-841-11 METAL CHIP 47K 5% 1/10W
R762 1-216-833-11 METAL CHIP 10K 5% 1/10W
R763 1-216-837-11 METAL CHIP 22K 5% 1/10W
R764 1-216-837-11 METAL CHIP 22K 5% 1/10W
R765 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R766 1-216-797-11 METAL CHIP 10 5% 1/10W
R767 1-216-849-11 METAL CHIP 220K 5% 1/10W
R768 1-216-833-11 METAL CHIP 10K 5% 1/10W
R770 1-216-841-11 METAL CHIP 47K 5% 1/10W
R771 1-216-821-11 METAL CHIP 1K 5% 1/10W
R772 1-216-821-11 METAL CHIP 1K 5% 1/10W
R775 1-216-805-11 METAL CHIP 47 5% 1/10W
R776 1-216-821-11 METAL CHIP 1K 5% 1/10W
R777 1-216-817-11 METAL CHIP 470 5% 1/10W
R778 1-216-821-11 METAL CHIP 1K 5% 1/10W
R779 1-216-821-11 METAL CHIP 1K 5% 1/10W
R781 1-216-833-11 METAL CHIP 10K 5% 1/10W
(US, CND)
R781 1-216-845-11 METAL CHIP 100K 5% 1/10W
(EXCEPT US, CND)
R782 1-216-833-11 METAL CHIP 10K 5% 1/10W
(SP, TW, KR, AUS)
R782 1-216-864-11 SHORT CHIP 0 (AEP, UK, EE, RU)
R783 1-216-833-11 METAL CHIP 10K 5% 1/10W
(AEP, UK, EE, RU)
R783 1-216-837-11 METAL CHIP 22K 5% 1/10W
(SP, TW, KR, AUS)
R784 1-216-845-11 METAL CHIP 100K 5% 1/10W
R785 1-216-833-11 METAL CHIP 10K 5% 1/10W
R787 1-216-841-11 METAL CHIP 47K 5% 1/10W
< SWITCH >
SW700 1-478-642-11 ENCODER, ROTARY (VOLUME)
SW701 1-762-875-21 SWITCH, KEYBOARD (I/1)
SW702 1-762-875-21 SWITCH, KEYBOARD (DSGX)
SW703 1-762-875-21 SWITCH, KEYBOARD ( –)
SW704 1-762-875-21 SWITCH, KEYBOARD ( +)
SW705 1-762-875-21 SWITCH, KEYBOARD (DISPLAY)
SW711 1-762-875-21 SWITCH, KEYBOARD (x)
SW712 1-762-875-21 SWITCH, KEYBOARD (TUNING –, m l)
SW713 1-762-875-21 SWITCH, KEYBOARD (TUNING +, M L)
SW714 1-762-875-21 SWITCH, KEYBOARD (FUNCTION)
SW715 1-762-875-21 SWITCH, KEYBOARD (TUNER, BAND)
SW716 1-762-875-21 SWITCH, KEYBOARD (CD u)
< VIBRATOR >
X701 1-760-252-12 VIBRATOR, CRYSTAL (32.768kHz)
X702 1-795-054-51 VIBRATOR, CERAMIC (4.19MHz)
************************************************************
A-1138-529-A PT-AC BOARD, COMPLETE
*********************
1-533-233-31 FUSE HOLDER
< CONNECTOR >
W002 1-819-131-11 PIN, CONNECTOR 3P
************************************************************
MISCELLANEOUS
**************
04 1-769-079-51 CORD, POWER (KR)
04 1-775-790-81 CORD, POWER (AUS)
04 1-790-757-51 CORD, POWER (US, CND)
04 1-827-597-81 CORD, POWER (TW)
04 1-830-891-11 CORD, POWER (UK)
04 1-831-370-11 CORD, POWER (AEP, EE, RU, SP)
70 1-797-374-11 DECK, MECHANICAL (H-21SB)
102 1-452-899-11 MAGNET
0151 8-820-126-01 OPTICAL PICK-UP BLOCK
(KSM-213CDP/C2NP)
(Including sled motor (M402),
spindle motor (M401))
152 1-832-404-21 CABLE, FLEXIBLE FLAT (16 CORE)
0F001 1-532-275-33 FUSE (T0.16AL/250V)
(AEP, UK, EE, RU, KR, AUS)
0F001 1-532-467-33 FUSE (T0.315AL/250V) (US, CND, SP, TW)
0F002 1-532-275-33 FUSE (T0.16AL/250V) (SP)
FFC151 1-832-627-21 CABLE, FLEXIBLE FLAT (23 CORE)
FFC701 1-832-634-21 CABLE, FLEXIBLE FLAT (25 CORE)
(US, CND, SP, TW, KR, AUS)
FFC702 1-832-644-21 CABLE, FLEXIBLE FLAT (27 CORE)
(AEP, UK, EE, RU)
0PT005 1-443-829-11 TRANSFORMER, POWER (AEP, UK, EE, RU)
0PT005 1-443-856-11 TRANSFORMER, POWER (US, CND)
0PT005 1-443-857-11 TRANSFORMER, POWER (KR)
0PT005 1-443-858-11 TRANSFORMER, POWER (SP, TW, AUS)
S201 1-771-853-11 SWITCH, DETECTION (LIMIT)
SW750 1-692-960-11 SWITCH, PUSH (1 KEY)
(CD LID OPEN/CLOSE DETECT)
*************************************************************
ACCESSORIES
************
0 1-569-008-22 ADAPTOR, CONVERSION 2P (SP)
0 1-770-019-61 ADAPTOR, CONVERSION PLUG (UK)
PT-AC
PANEL
Ver. 1.4
Refer to the SUPPLEMENT-1 for the PT-AC board
of the except AEP, UK, East European and Russian
models.
