Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-EH15
34
C861 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V (UK)
C862 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V (UK)
C863 1-126-965-91 ELECT 22uF 20% 50V (UK)
C864 1-162-962-11 CERAMIC CHIP 470PF 10% 50V (UK)
C865 1-126-965-91 ELECT 22uF 20% 50V (UK)
C866 1-162-962-11 CERAMIC CHIP 470PF 10% 50V (UK)
C867 1-162-962-11 CERAMIC CHIP 470PF 10% 50V (UK)
C868 1-162-925-11 CERAMIC CHIP 68PF 5% 50V (UK)
C869 1-162-923-11 CERAMIC CHIP 47PF 5% 50V (UK)
C873 1-162-907-11 CERAMIC CHIP 2PF 0.25PF 50V
< FILTER/CAPACITOR >
CF801 1-795-426-11 FILTER, CERAMIC
CF802 1-128-821-51 CERAMIC 1000PF 5% 50V
(EXCEPT UK, RU)
CF802 1-579-554-21 FILTER, CERAMIC (UK, RU)
CF803 1-781-962-21 FILTER, CERAMIC
< CONNECTOR >
CN105 1-784-778-11 CONNECTOR, FFC 17P
CN106 1-784-766-11 CONNECTOR, FFC 5P (EXCEPT UK)
CN106 1-568-826-11 CONNECTOR, FFC 7P (UK)
CNP501 1-815-445-11 PIN, CONNECTOR (PWB) 4P
CNP502 1-815-444-11 PIN, CONNECTOR (PWB) 3P
* CNP802 1-506-680-11 PLUG, CONNECTOR (2.5mm) 3P
(ANTENNA FM/AM)
< DIODE >
D106 6-501-172-01 DIODE UDZW-TE17-8.2B
D107 6-502-411-01 DIODE RL202-B322-1
D108 6-502-411-01 DIODE RL202-B322-1
D109 6-502-411-01 DIODE RL202-B322-1
D110 6-502-411-01 DIODE RL202-B322-1
D111 6-501-582-01 DIODE 1N4002-B5
D112 6-501-582-01 DIODE 1N4002-B5 (E51, SP)
D113 6-501-582-01 DIODE 1N4002-B5
D114 6-501-582-01 DIODE 1N4002-B5 (E51, SP)
D131 6-500-334-01 DIODE MC2836-T112-1
D193 6-500-335-01 DIODE MC2838-T112-1
D371 6-500-335-01 DIODE MC2838-T112-1
D372 6-500-335-01 DIODE MC2838-T112-1
D802 6-501-369-01 DIODE SVC230-TB-E
D803 6-501-369-01 DIODE SVC230-TB-E
D812 6-501-579-01 DIODE MC2837
D813 6-501-579-01 DIODE MC2837
D815 6-501-579-01 DIODE MC2837
D851 6-501-142-01 DIODE SVC347A-TL-E
< FERRITE BEAD >
FB101 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB102 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB103 1-469-152-11 FERRITE, EMI (SMD) (2012)
< IC >
IC101 6-710-863-01 IC TK70540SCL-G
IC301 6-706-641-01
IC LA4631-E
IC401 6-702-895-01 IC BD3881FV
IC801 6-708-840-01 IC LV23003VA
IC861 6-708-918-01 IC PT2579SN (UK)
< JACK/TERMINAL BOARD >
J101 1-780-314-1
1 TERMINAL BOARD (SPEAKER)
J102 1-815-629-11 JACK (PHONES)
J105 1-566-822-51 JACK (AUDIO IN)
< JUMPER RESISTOR >
JR101 1-216-864-11 SHORT CHIP 0 (KR)
JR102 1-216-864-11 SHORT CHIP 0 (MX, TW)
JR103 1-216-864-11 SHORT CHIP 0 (AR, AUS)
JR104 1-216-864-11 SHORT CHIP 0 (E51, SP)
JR105 1-216-864-11 SHORT CHIP 0 (CND)
JR106 1-216-864-11 SHORT CHIP 0 (UK)
JR107 1-216-864-11 SHORT CHIP 0 (RU)
JR401 1-216-864-11 SHORT CHIP 0
JR402 1-216-864-11 SHORT CHIP 0
JR403 1-216-864-11 SHORT CHIP 0
JR404 1-216-864-11 SHORT CHIP 0
JR801 1-216-864-11 SHORT CHIP 0
JR802 1-216-864-11 SHORT CHIP 0
JR803 1-216-864-11 SHORT CHIP 0
JR861 1-216-864-11 SHORT CHIP 0 (UK)
< RESISTOR >
JW137 1-249-385-11 CARBON 2.2 5% 1/4W
(CND)
< COIL/FERRITE BEAD >
L103 1-469-152-11 FERRITE, EMI (SMD) (2012)
L104 1-410-509-11 INDUCTOR 10uH
L501 1-456-094-11 TRANSFORMER, BIAS OSCILLATION
L803 1-433-741-11 TRANSFORMER, IF
L804 1-457-163-22 COIL, AIR-CORE
L805 1-457-162-22 COIL, AIR-CORE
L806 1-457-168-11 COIL, DET
L851 1-457-161-11 COIL, AM ANTENNA
L852 1-456-596-11 COIL, MW OSC
< TRANSISTOR >
Q101 8-729-024-93 TRANSISTOR 2SB1565E
Q102 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q103 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q121 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q122 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q123 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q191 8-729-036-86 TRANSISTOR KTC3203Y-AT
Q192 8-729-036-86 TRANSISTOR KTC3203Y-AT
Q193 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
Q194 8-729-037-13 TRANSISTOR KTA1271Y
Q195 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q351 6-551-703-01 FET 2SJ599-ZK-E1-AZ
Q352 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q371 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
Q372 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q507 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q801 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q802 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q803 6-550-304-01 TRANSISTOR 2SC5477-T122-1
Q861 8-729-120-28 TRANSISTOR 2SC1623-L5L6 (UK)
Q862 8-729-120-28 TRANSISTOR 2SC1623-L5L6 (UK)
MAIN
To Next Page
