30
HCD-EP30/EP40
SECTION 8
ELECTRICAL PARTS LIST
CASSETTE
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
A-4726-711-A CASSETTE BOARD, COMPLETE
*************************
< CAPACITOR >
C701 1-130-474-00 FILM 0.0018uF 5% 50V
C702 1-130-474-00 FILM 0.0018uF 5% 50V
C703 1-130-495-00 FILM 0.1uF 5% 50V
C704 1-130-495-00 FILM 0.1uF 5% 50V
C705 1-162-286-31 CERAMIC 220PF 10% 50V
C706 1-162-286-31 CERAMIC 220PF 10% 50V
C707 1-104-665-11 ELECT 100uF 20% 10V
C708 1-104-665-11 ELECT 100uF 20% 10V
C709 1-164-159-11 CERAMIC 0.1uF 50V
C710 1-164-159-11 CERAMIC 0.1uF 50V
C711 1-126-964-11 ELECT 10uF 20% 50V
C712 1-126-964-11 ELECT 10uF 20% 50V
C713 1-126-960-11 ELECT 1uF 20% 50V
C714 1-126-960-11 ELECT 1uF 20% 50V
C715 1-126-956-91 ELECT 0.1uF 20% 50V
C716 1-126-956-91 ELECT 0.1uF 20% 50V
C717 1-130-473-00 FILM 0.0015uF 5% 50V
C718 1-130-473-00 FILM 0.0015uF 5% 50V
C719 1-126-964-11 ELECT 10uF 20% 50V
C720 1-104-664-11 ELECT 47uF 20% 10V
C721 1-126-935-11 ELECT 470uF 20% 16V
C722 1-161-494-00 CERAMIC 0.022uF 25V
C723 1-128-551-11 ELECT 22uF 20% 25V
C724 1-161-494-00 CERAMIC 0.022uF 25V
C725 1-130-476-00 FILM 0.0027uF 5% 50V
C726 1-162-288-31 CERAMIC 330PF 10% 50V
C727 1-161-494-00 CERAMIC 0.022uF 25V
C728 1-126-964-11 ELECT 10uF 20% 50V
C729 1-130-487-00 FILM 0.022uF 5% 50V
C730 1-130-481-00 FILM 0.0068uF 5% 50V
C731 1-162-282-31 CERAMIC 100PF 10% 50V
C732 1-162-282-31 CERAMIC 100PF 10% 50V
< CONNECTOR >
* CN701 1-695-645-11 PLUG (CONNECTOR) 4P
< DIODE >
D701 8-719-991-33 DIODE 1SS133T-77
D702 8-719-991-33 DIODE 1SS133T-77
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
< IC >
IC701 6-700-579-01 IC AN7312
< TRANSISTOR >
Q701 8-729-194-57 TRANSISTOR 2SC945-P
Q702 8-729-194-57 TRANSISTOR 2SC945-P
Q703 8-729-194-57 TRANSISTOR 2SC945-P
Q704 8-729-194-57 TRANSISTOR 2SC945-P
Q705 8-729-194-57 TRANSISTOR 2SC945-P
Q706 8-729-116-82 TRANSISTOR 2SD1616-L
< RESISTOR >
R701 1-249-393-11 CARBON 10 5% 1/4W
R702 1-249-393-11 CARBON 10 5% 1/4W
R703 1-249-434-11 CARBON 27K 5% 1/4W
R704 1-249-434-11 CARBON 27K 5% 1/4W
R705 1-249-433-11 CARBON 22K 5% 1/4W
R706 1-249-433-11 CARBON 22K 5% 1/4W
R707 1-249-418-11 CARBON 1.2K 5% 1/4W
R708 1-249-418-11 CARBON 1.2K 5% 1/4W
R709 1-249-413-11 CARBON 470 5% 1/4W
R710 1-249-413-11 CARBON 470 5% 1/4W
R711 1-249-438-11 CARBON 56K 5% 1/4W
R712 1-249-438-11 CARBON 56K 5% 1/4W
R713 1-249-433-11 CARBON 22K 5% 1/4W
R714 1-249-433-11 CARBON 22K 5% 1/4W
R715 1-249-429-11 CARBON 10K 5% 1/4W
R716 1-249-429-11 CARBON 10K 5% 1/4W
R719 1-249-426-11 CARBON 5.6K 5% 1/4W
R720 1-249-426-11 CARBON 5.6K 5% 1/4W
R721 1-249-429-11 CARBON 10K 5% 1/4W
R722 1-249-429-11 CARBON 10K 5% 1/4W
R723 1-247-893-11 CARBON 390K 5% 1/4W
R724 1-249-441-11 CARBON 100K 5% 1/4W
R725 1-249-411-11 CARBON 330 5% 1/4W
R726 1-249-437-11 CARBON 47K 5% 1/4W
R727 1-249-430-11 CARBON 12K 5% 1/4W
R728 1-249-437-11 CARBON 47K 5% 1/4W
R729 1-249-437-11 CARBON 47K 5% 1/4W
R730 1-249-437-11 CARBON 47K 5% 1/4W
R731 1-247-847-11 CARBON 4.7K 5% 1/4W
R732 1-249-411-11 CARBON 330 5% 1/4W
• Abbreviation
AR : Argentina model
AUS : Australian model
CND : Canadian model
EA : Saudi Arabia model
Les composants identifiés par une
marque 0 sont critiquens pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
MX : Mexican model
SP : Singapore model
TW : Taiwan model
