6
HCD-FR1/FR8/FR9
3 boss
4 boss
5 boss
6 optical pick-up section
(DVBU16)
1 screw
(PTPWHM2.6
)
2
1-8. TUNER UNIT, IO BOARD
1-9. OPTICAL PICK-UP SECTION (DVBU16)
6 IO board
5 wire (flat type)
(29 core) (CN601)
4 wire (flat type)
(15 core) (CN201)
2 wire (flat type)
(11 core)
3 tuner unit
1 eight screw
s
(+BV3)
