Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-FX200/FX205
3737
R125 1-216-833-11 METAL CHIP 10K 5% 1/10W
R126 1-216-864-11 SHORT CHIP 0
R201 1-218-446-11 METAL CHIP 1 5% 1/10W
R202 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R203 1-216-864-11 SHORT CHIP 0
R301 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
R302 1-216-839-11 METAL CHIP 33K 5% 1/10W
R303 1-216-834-11 METAL CHIP 12K 5% 1/10W
R304 1-216-833-11 METAL CHIP 10K 5% 1/10W
R305 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R401 1-216-295-91 SHORT CHIP 0
R402 1-216-295-91 SHORT CHIP 0
R403 1-216-809-11 METAL CHIP 100 5% 1/10W
R404 1-216-809-11 METAL CHIP 100 5% 1/10W
R405 1-216-809-11 METAL CHIP 100 5% 1/10W
R406 1-216-809-11 METAL CHIP 100 5% 1/10W
R407 1-216-809-11 METAL CHIP 100 5% 1/10W
R408 1-216-809-11 METAL CHIP 100 5% 1/10W
R409 1-216-809-11 METAL CHIP 100 5% 1/10W
R411 1-216-809-11 METAL CHIP 100 5% 1/10W
R412 1-216-809-11 METAL CHIP 100 5% 1/10W
R413 1-216-809-11 METAL CHIP 100 5% 1/10W
R417 1-216-295-91 SHORT CHIP 0
< VIBRATOR >
X101 1-795-101-21 VIBRATOR, CERAMIC (16.934MHz)
*************************************************************
A-1749-735-A MAIN BOARD, COMPLETE (AEP)
A-1749-736-A MAIN BOARD, COMPLETE (SP, TW, AR, TH, AUS)
A-1765-499-A MAIN BOARD, COMPLETE (E2, E51, EA)
A-1766-840-A MAIN BOARD, COMPLETE (RU, KR)
*********************
7-685-646-71 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
C150 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C152 1-126-960-11 ELECT 1uF 20% 50V
C153 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C154 1-126-767-11 ELECT 1000uF 20% 16V
C155 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C156 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C157 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C158 1-126-960-11 ELECT 1uF 20% 50V
C159 1-104-662-91 ELECT 22uF 20% 25V
C160 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C250 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C252 1-126-960-11 ELECT 1uF 20% 50V
C253 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C254 1-126-767-11 ELECT 1000uF 20% 16V
C255 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C256 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C257 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C258 1-126-960-11 ELECT 1uF 20% 50V
C259 1-104-662-91 ELECT 22uF 20% 25V
C260 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C350 1-126-933-11 ELECT 100uF 20% 16V
C351 1-126-963-11 ELECT 4.7uF 20% 50V
C352 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C353 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C355 1-126-943-11 ELECT 2200uF 20% 25V
C901 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C902 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C903 1-126-943-11 ELECT 2200uF 20% 25V
C904 1-126-972-11 ELECT 1000uF 20% 50V
C906 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C907 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C908 1-126-923-91 ELECT 220uF 20% 10V
C910 1-126-964-11 ELECT 10uF 20% 50V
C914 1-126-925-91 ELECT 470uF 20% 10V
C915 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C930 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C940 1-126-964-11 ELECT 10uF 20% 50V
C5001 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C5002 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C5003 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5004 1-126-960-11 ELECT 1uF 20% 50V
C5006 1-126-963-11 ELECT 4.7uF 20% 50V
C5007 1-104-662-91 ELECT 22uF 20% 25V
C5008 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C5010 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C5011 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C5012 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C5013 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C5014 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C5015 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C5016 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C5017 1-104-662-91 ELECT 22uF 20% 25V
C5018 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C5019 1-162-925-11 CERAMIC CHIP 68PF 5% 50V (AEP)
C5020 1-165-908-11 CERAMIC CHIP 1uF 10% 10V (AEP)
C5021 1-162-923-11 CERAMIC CHIP 47PF 5% 50V (AEP)
C5022 1-164-315-11 CERAMIC CHIP 470PF 5% 50V (AEP)
C5023 1-165-908-11 CERAMIC CHIP 1uF 10% 10V (AEP)
C5024 1-165-908-11 CERAMIC CHIP 1uF 10% 10V (AEP)
C5025 1-164-315-11 CERAMIC CHIP 470PF 5% 50V (AEP)
C5026 1-104-658-91 ELECT 100uF 20% 10V
< CONNECTOR >
CN901 1-819-134-11 PIN, CONNECTOR 6P
CN902 1-819-131-11 PIN, CONNECTOR 3P
CN904 1-819-131-11 PIN, CONNECTOR 3P
CN911 1-784-784-11 CONNECTOR, FFC 23P (AEP)
CN912 1-568-838-11 CONNECTOR, FFC 21P (RU, E2, E51, EA, SP, TW,
AR, KR, TH, AUS)
CN913 1-819-130-11 PIN, CONNECTOR 2P
CN914 1-819-130-11 PIN, CONNECTOR 2P
* CN5001 1-506-680-11 PLUG, CONNECTOR (2.5mm) 3P
(FM/AM ANTENNA)
< DIODE >
D902 6-501-569-01 DIODE 1N5401-C352
D903 6-501-569-01 DIODE 1N5401-C352
D905 6-502-411-01 DIODE RL202-B322-1
D906 6-502-411-01 DIODE RL202-B322-1
D907 6-501-582-01 DIODE 1N4002-A2
D910 6-502-972-01 DIODE DZ2J09100L
D913 6-503-025-01 DIODE DZ2J12000L
D914 6-502-972-01 DIODE DZ2J09100L
D920 6-502-961-01 DIODE DA2J10100L
D930 6-502-961-01 DIODE DA2J10100L
BD73U MAIN
Ver. 1.1
