86
HCD-FX888K
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C203 1-126-933-11 ELECT 100uF 20% 16V
C204 1-126-964-11 ELECT 10uF 20% 50V
C205 1-126-964-11 ELECT 10uF 20% 50V
C206 1-124-261-00 ELECT 10uF 20% 25V
C207 1-126-964-11 ELECT 10uF 20% 50V
C208 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C209 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C210 1-126-925-91 ELECT 470uF 20% 10V
C211 1-126-964-11 ELECT 10uF 20% 50V
C212 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
C213 1-126-933-11 ELECT 100uF 20% 16V
C214 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C215 1-115-156-11 CERAMIC CHIP 1uF 10V
C216 1-115-156-11 CERAMIC CHIP 1uF 10V
C217 1-126-933-11 ELECT 100uF 20% 16V
C218 1-115-156-11 CERAMIC CHIP 1uF 10V
C219 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C220 1-126-964-11 ELECT 10uF 20% 50V
C221 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C222 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C223 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C224 1-126-916-11 ELECT 1000uF 20% 6.3V
C225 1-126-916-11 ELECT 1000uF 20% 6.3V
C226 1-126-916-11 ELECT 1000uF 20% 6.3V
C227 1-126-933-11 ELECT 100uF 20% 16V
C228 1-126-933-11 ELECT 100uF 20% 16V
C231 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C242 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C601 1-126-933-11 ELECT 100uF 20% 16V
C602 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C605 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C606 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C607 1-104-662-91 ELECT 22uF 20% 25V
C608 1-126-933-11 ELECT 100uF 20% 16V
C609 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C610 1-104-662-91 ELECT 22uF 20% 25V
C611 1-124-234-00 ELECT 22uF 20% 16V
C612 1-104-662-91 ELECT 22uF 20% 25V
C613 1-104-662-91 ELECT 22uF 20% 25V
C614 1-104-662-91 ELECT 22uF 20% 25V
C615 1-126-960-11 ELECT 1uF 20% 50V
C616 1-126-960-11 ELECT 1uF 20% 50V
C617 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C622 1-104-662-91 ELECT 22uF 20% 25V
C623 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C624 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C625 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C626 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C627 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C628 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C630 1-124-234-00 ELECT 22uF 20% 16V
C645 1-130-491-00 MYLAR 0.047uF 5% 50V
C646 1-126-933-11 ELECT 100uF 20% 16V
C647 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C648 1-124-464-11 ELECT 0.22uF 20% 50V
C649 1-125-972-91 ELECT 100uF 20% 16V
C650 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C654 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C655 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C665 1-126-933-11 ELECT 100uF 20% 16V
C666 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C668 1-124-234-00 ELECT 22uF 20% 16V
C669 1-125-972-91 ELECT 100uF 20% 16V
C670 1-164-156-11 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
CN101 1-568-828-11 CONNECTOR, FFC 9P
CN201 1-779-281-11 CONNECTOR, FFC (LIF (NON-ZIF)) 13P
CN601 1-779-291-11 CONNECTOR, FFC (LIF (NON-ZIF)) 23P
* CN602 1-564-708-11 PIN, CONNECTOR (SMALL TYPE) 6P
< IC >
IC201 6-705-602-01 IC MM1623BFBE
IC203 8-759-696-10 IC NJM2235V (TE2)
IC204 8-759-284-49 IC NJM2285V-TE2
IC601 8-759-385-76 IC MC14052 BDR2
IC602 8-759-649-89 IC MC4558CD
IC603 6-600-014-01 IC TORX141L (OPTICAL DIGITAL IN)
IC606 8-759-649-89 IC MC4558CD
IC607 6-706-078-01 IC M62429FP-TP
< JACK >
J201 1-780-211-11 TERMINAL BOARD (S TERMINAL+1P)
(MONITOR OUT)
J202 1-817-449-11 JACK, PIN 3P (COMPONENT VIDEO OUT)
J601 1-816-605-11 JACK, PIN 6P (VIDEO/SAT)
< COIL >
L101 1-469-525-91 INDUCTOR 10uH
L201 1-469-525-91 INDUCTOR 10uH
L202 1-469-525-91 INDUCTOR 10uH
L601 1-469-525-91 INDUCTOR 10uH
L602 1-469-525-91 INDUCTOR 10uH
L603 1-469-525-91 INDUCTOR 10uH
< TRANSISTOR >
Q600 8-729-901-00 TRANSISTOR DTC124EK
Q601 8-729-901-00 TRANSISTOR DTC124EK
Q602 8-729-901-00 TRANSISTOR DTC124EK
Q603 8-729-901-00 TRANSISTOR DTC124EK
Q604 8-729-901-00 TRANSISTOR DTC124EK
Q605 8-729-901-00 TRANSISTOR DTC124EK
< RESISTOR >
R102 1-216-864-11 SHORT CHIP 0
R105 1-216-845-11 METAL CHIP 100K 5% 1/10W
R109 1-216-864-11 SHORT CHIP 0
R114 1-216-864-11 SHORT CHIP 0
R115 1-216-845-11 METAL CHIP 100K 5% 1/10W
R116 1-216-845-11 METAL CHIP 100K 5% 1/10W
R117 1-216-845-11 METAL CHIP 100K 5% 1/10W
R201 1-218-285-11 METAL CHIP 75 5% 1/10W
R202 1-218-285-11 METAL CHIP 75 5% 1/10W
R203 1-216-864-11 SHORT CHIP 0
R204 1-216-821-11 METAL CHIP 1K 5% 1/10W
