87
HCD-FX888K
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R205 1-216-864-11 SHORT CHIP 0
R206 1-216-864-11 SHORT CHIP 0
R207 1-216-864-11 SHORT CHIP 0
R209 1-216-864-11 SHORT CHIP 0
R226 1-216-864-11 SHORT CHIP 0
R228 1-216-833-11 METAL CHIP 10K 5% 1/10W
R229 1-218-285-11 METAL CHIP 75 5% 1/10W
R230 1-218-285-11 METAL CHIP 75 5% 1/10W
R231 1-218-285-11 METAL CHIP 75 5% 1/10W
R232 1-218-285-11 METAL CHIP 75 5% 1/10W
R233 1-218-285-11 METAL CHIP 75 5% 1/10W
R241 1-218-285-11 METAL CHIP 75 5% 1/10W
R601 1-216-833-11 METAL CHIP 10K 5% 1/10W
R602 1-216-833-11 METAL CHIP 10K 5% 1/10W
R603 1-216-833-11 METAL CHIP 10K 5% 1/10W
R604 1-216-833-11 METAL CHIP 10K 5% 1/10W
R607 1-216-841-11 METAL CHIP 47K 5% 1/10W
R608 1-216-841-11 METAL CHIP 47K 5% 1/10W
R609 1-216-817-11 METAL CHIP 470 5% 1/10W
R610 1-216-817-11 METAL CHIP 470 5% 1/10W
R613 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R614 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R615 1-216-841-11 METAL CHIP 47K 5% 1/10W
R616 1-216-841-11 METAL CHIP 47K 5% 1/10W
R617 1-216-821-11 METAL CHIP 1K 5% 1/10W
R618 1-216-833-11 METAL CHIP 10K 5% 1/10W
R619 1-216-821-11 METAL CHIP 1K 5% 1/10W
R620 1-216-833-11 METAL CHIP 10K 5% 1/10W
R621 1-216-833-11 METAL CHIP 10K 5% 1/10W
R622 1-216-833-11 METAL CHIP 10K 5% 1/10W
R623 1-216-841-11 METAL CHIP 47K 5% 1/10W
R624 1-216-841-11 METAL CHIP 47K 5% 1/10W
R625 1-216-841-11 METAL CHIP 47K 5% 1/10W
R626 1-216-841-11 METAL CHIP 47K 5% 1/10W
R627 1-216-841-11 METAL CHIP 47K 5% 1/10W
R628 1-216-841-11 METAL CHIP 47K 5% 1/10W
R629 1-216-833-11 METAL CHIP 10K 5% 1/10W
R630 1-216-833-11 METAL CHIP 10K 5% 1/10W
R634 1-216-845-11 METAL CHIP 100K 5% 1/10W
R635 1-216-841-11 METAL CHIP 47K 5% 1/10W
R636 1-216-833-11 METAL CHIP 10K 5% 1/10W
R640 1-216-864-11 SHORT CHIP 0
R641 1-216-841-11 METAL CHIP 47K 5% 1/10W
R642 1-216-841-11 METAL CHIP 47K 5% 1/10W
R643 1-216-833-11 METAL CHIP 10K 5% 1/10W
R645 1-216-837-11 METAL CHIP 22K 5% 1/10W
R648 1-216-833-11 METAL CHIP 10K 5% 1/10W
R649 1-216-833-11 METAL CHIP 10K 5% 1/10W
R650 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R651 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R652 1-216-809-11 METAL CHIP 100 5% 1/10W
R653 1-216-845-11 METAL CHIP 100K 5% 1/10W
R654 1-216-841-11 METAL CHIP 47K 5% 1/10W
R655 1-216-835-11 METAL CHIP 15K 5% 1/10W
R656 1-216-835-11 METAL CHIP 15K 5% 1/10W
R657 1-216-809-11 METAL CHIP 100 5% 1/10W
R659 1-216-809-11 METAL CHIP 100 5% 1/10W
R660 1-216-809-11 METAL CHIP 100 5% 1/10W
R669 1-216-864-11 SHORT CHIP 0
R670 1-216-864-11 SHORT CHIP 0
************************************************************
KEY BOARD
*********
< RESISTOR >
R851 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R852 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R853 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R855 1-216-821-11 METAL CHIP 1K 5% 1/10W
R856 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R857 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R858 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
< SWITCH >
S801 1-786-763-11 SWITCH, TACTILE (.)
S802 1-786-763-11 SWITCH, TACTILE (VOLUME +)
S804 1-786-763-11 SWITCH, TACTILE (FUNCTION)
S805 1-786-763-11 SWITCH, TACTILE (X)
S806 1-786-763-11 SWITCH, TACTILE (x)
S807 1-786-763-11 SWITCH, TACTILE (>)
S808 1-786-763-11 SWITCH, TACTILE (VOLUME –)
************************************************************
LED BOARD
*********
< CONNECTOR >
CN803 1-784-867-21 CONNECTOR, FFC (LIF (NON-ZIF)) 15P
< DIODE >
D811 8-719-079-89 DIODE SML-020MDT-T86 (DISC1)
D812 8-719-079-89 DIODE SML-020MDT-T86 (DISC2)
D813 8-719-079-89 DIODE SML-020MDT-T86 (DISC3)
D814 8-719-079-89 DIODE SML-020MDT-T86 (DISC4)
D815 8-719-079-89 DIODE SML-020MDT-T86 (DISC5)
< RESISTOR >
R822 1-216-817-11 METAL CHIP 470 5% 1/10W
R823 1-216-817-11 METAL CHIP 470 5% 1/10W
R824 1-216-817-11 METAL CHIP 470 5% 1/10W
R825 1-216-817-11 METAL CHIP 470 5% 1/10W
R826 1-216-817-11 METAL CHIP 470 5% 1/10W
R827 1-216-817-11 METAL CHIP 470 5% 1/10W
R828 1-216-817-11 METAL CHIP 470 5% 1/10W
R829 1-216-817-11 METAL CHIP 470 5% 1/10W
R830 1-216-817-11 METAL CHIP 470 5% 1/10W
R831 1-216-817-11 METAL CHIP 470 5% 1/10W
R833 1-216-821-11 METAL CHIP 1K 5% 1/10W
R834 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R835 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R836 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R837 1-216-833-11 METAL CHIP 10K 5% 1/10W
R838 1-216-837-11 METAL CHIP 22K 5% 1/10W
R839 1-216-841-11 METAL CHIP 47K 5% 1/10W
