HCD-G2BNiP/G2NiP
52
– DAB Board –
IC4001 MM3291CNRE
VDD 1
GND
2
CE
3
NC4
REGULATOR
VOUT
5
– NET Board –
IC5001 SI-3010KM-TLS
1VC
TSD
2VIN
3GND
4VOUT
5ADJ
+
–
REF
IC5002 SRC4182
1LGRP
18 OFMT1
17 OWL0
16 OWL1
20 TDMI
19 OFMT0
24 LRCKO
23 SDOUT
26 MODE0
25 BCKO
28
MODE2
27
MODE1
22 VDD
21 DGND
15 RDY
2RCKI
3NC
4SDIN
5BCKI
6LRCKI
9BYPAS
10IFMT0
11IFMT1
12IFMT2
13RST
14MUTE
7VIO
8DGND
REFERENCE
CLOCK
INTERPOLATION
FILTERS
RE-SAMPLER
DECIMATION
FILTERS
AUDIO
OUTPUT
PORT
AUDIO
INPUT
PORT
RATE
ESTIMATOR
CONTROL
LOGIC
IC5003 BD9329AEFJ-E2
VREFOSC
IBIAS
SLOPE
UNDER VOLTAGE
LOCK OUT
ERROR
AMP
DRIVE
LOGIC
S
R
PWM
THERMAL
SHUTDOWN
LVS
LVS
OVER CURRENT
PROTECT
VREG
VCC
SOFT
START
BST 1
VIN
2
SW
3
GND
4
EN
7
FB
5
COMP6
SS
8
