12
HCD-GB3
8
Remove soldering from
the four points.
7
wire (flat type) (16 core
(CN301)
q;
BD83S board
9
optical pick-up
(KSM-213DCP)
4
two screws
(+PTPWHM 2.6)
1
two screws
(+PTPWHM 2.6)
2
two coil springs (insulator)
3
two insulators
5
two coil springs (insulator)
6
two insulators
3-11. OPTICAL PICK-UP (KSM-213DCP), BD83S BOARD
