Sony HCD-GB3 - Printed Wiring Board - AMP Board

3131
HCD-GB3
HCD-GB3
7-10. PRINTED WIRING BOARD — AMP BOARD —
• See page 21 for Circuit Boards Location. :Uses unleaded solder.
• Semiconductor
Location
Ref. No. Location
D241 B-4
IC202 C-3
Q201 B-3
Q202 B-4
Q241 B-2
Q242 B-2
Q243 B-3
Q244 B-3
Q901 B-1
Q902 B-2
Q903 B-1
A
MAIN
BOARD
WH102
(Page 27)
D
MAIN
BOARD
WH901
(Page 27)
B
MAIN
BOARD
WH101
(Page 27)
IC202
1
31
15
4
E
E
E
E
E
E
E
E
E
-VP
R-OUT
AMP BOARD
FAN
12
A
B
C
345
