HCD-GB3
Adjustment Location and Connecting Points
L851
CNP802
L852
L804
L805
AM TRACKING
ADJUSTMENT
FM TRACKING
ADJUSTMENT
(TUNER GND)
(TUNER VT)
FM FREQUENCY
COVERRANGE
ADUJUSTMENT
AM FREQUENCY
COVERRANGE
ADUJUSTMENT
FM DETECTOR
ADUJUSTMENT
– MAIN BOARD (Component side) –
– MAIN BOARD (Condutor side) –
L806
TP (TUNER VT)
TP (TUNER GND)
IC801 pin qs
(TUNER OUT L-ch)
