52
HCD-GB3
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R109 1-216-809-11 METAL CHIP 100 5% 1/10W
R110 1-216-809-11 METAL CHIP 100 5% 1/10W
R111 1-216-809-11 METAL CHIP 100 5% 1/10W
R112 1-216-809-11 METAL CHIP 100 5% 1/10W
R113 1-216-809-11 METAL CHIP 100 5% 1/10W
R201 1-216-295-91 SHORT CHIP 0
R202 1-216-295-91 SHORT CHIP 0
R203 1-500-445-21 FERRITE, EMI (SMD) (2012)
R207 1-216-295-91 SHORT CHIP 0
R250 1-216-857-11 METAL CHIP 1M 5% 1/10W
R252 1-216-833-11 METAL CHIP 10K 5% 1/10W
R253 1-216-821-11 METAL CHIP 1K 5% 1/10W
R254 1-216-833-11 METAL CHIP 10K 5% 1/10W
R255 1-216-821-11 METAL CHIP 1K 5% 1/10W
R256 1-216-837-11 METAL CHIP 22K 5% 1/10W
R257 1-216-845-11 METAL CHIP 100K 5% 1/10W
R258 1-216-849-11 METAL CHIP 220K 5% 1/10W
R260 1-216-864-11 SHORT CHIP 0
R265 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R266 1-216-821-11 METAL CHIP 1K 5% 1/10W
R267 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R268 1-216-833-11 METAL CHIP 10K 5% 1/10W
R270 1-216-821-11 METAL CHIP 1K 5% 1/10W
R271 1-216-857-11 METAL CHIP 1M 5% 1/10W
R275 1-216-809-11 METAL CHIP 100 5% 1/10W
R276 1-216-841-11 METAL CHIP 47K 5% 1/10W
R277 1-216-809-11 METAL CHIP 100 5% 1/10W
R278 1-216-809-11 METAL CHIP 100 5% 1/10W
R280 1-216-864-11 SHORT CHIP 0
R291 1-216-809-11 METAL CHIP 100 5% 1/10W
R292 1-216-809-11 METAL CHIP 100 5% 1/10W
R321 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R322 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R323 1-216-864-11 SHORT CHIP 0
R324 1-216-845-11 METAL CHIP 100K 5% 1/10W
R401 1-216-295-91 SHORT CHIP 0
R421 1-216-864-11 SHORT CHIP 0
R423 1-216-833-11 METAL CHIP 10K 5% 1/10W
R451 1-216-837-11 METAL CHIP 22K 5% 1/10W
R452 1-216-833-11 METAL CHIP 10K 5% 1/10W
< VIBRATOR >
X201 1-795-101-21 VIBRATOR, CERAMIC (16.9344MHz)
*************************************************************
A-1177-470-A JACK BOARD
***********
< CAPACITOR >
C139 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C140 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C141 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C142 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
< JACK >
J102 1-815-629-11 JACK (PHONES)
J105 1-566-822-51 JACK (AUDIO IN)
< JUMPER RESISTOR >
JR111 1-216-864-11 SHORT CHIP 0
< COIL >
L103 1-469-152-11 FERRITE, EMI (SMD) (2012)
L104 1-469-152-11 FERRITE, EMI (SMD) (2012)
L105 1-216-295-91 SHORT CHIP 0
L106 1-216-295-91 SHORT CHIP 0
< RESISTOR >
R119 1-216-805-11 METAL CHIP 47 5% 1/10W
R120 1-216-805-11 METAL CHIP 47 5% 1/10W
R151 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R152 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R175 1-216-841-11 METAL CHIP 47K 5% 1/10W
R176 1-216-841-11 METAL CHIP 47K 5% 1/10W
< CABLE HOLDER >
WH171 1-819-972-11 HOLDER, CABLE 8P
*************************************************************
A-1177-468-A MAIN BOARD, COMPLETE
*********************
< CAPACITOR >
C101 1-128-550-11 ELECT 2200uF 20% 50V
C102 1-128-550-11 ELECT 2200uF 20% 50V
C105 1-165-621-91 CERAMIC CHIP 0.1uF 50V
C106 1-165-621-91 CERAMIC CHIP 0.1uF 50V
C111 1-126-933-11 ELECT 100uF 20% 16V
C112 1-126-943-11 ELECT 2200uF 20% 25V
C113 1-126-942-61 ELECT 1000uF 20% 25V
C114 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C115 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C116 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C121 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V
C130 1-126-923-91 ELECT 220uF 20% 10V
C131 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C132 1-165-621-91 CERAMIC CHIP 0.1uF 50V
C133 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C134 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C151 1-126-933-11 ELECT 100uF 20% 16V
C152 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C153 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C155 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C156 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C158 1-165-621-91 CERAMIC CHIP 0.1uF 50V
C159 1-165-621-91 CERAMIC CHIP 0.1uF 50V
C181 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C182 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C183 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C184 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C187 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C188 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C191 1-126-923-91 ELECT 220uF 20% 10V
C192 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C193 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
