Sony HCD-GN880 - Case; Loading Panel Assy

8
HCD-GN880
Note: Follow the disassembly procedure in the numerical order given.
3-2. CASE
3-3. LOADING PANEL ASSY
1 two screws
(case 3 TP2)
(M3 x 8)
2 screw
(case 3 TP2) (M3 x 12)
3 five screws
(+BVTT3 x 6)
7 case
6
5
1
two screws
(case 3 TP2) (M3 x 8)
2 screw (case 3 TP2
)
(M3 x 12)
4 two screws
(+BVTT3 x 6)
CD mechanismdeck (CDM74-F1BD81)
1 Turn the pulley to the arrow direction.
Front side
Pulley
4 loading panel assy
3
2
Pull out disc tray
