Sony HCD-GN880 - Front Panel Assy; CD Mechanism Deck (CDM74-F1 BD81)

9
HCD-GN880
3-4. FRONT PANEL ASSY
3-5. CD MECHANISM DECK (CDM74-F1BD81)
3 screw (BVTP3 x 10)
2 five screws (BVTP3 x 10)
9 front panel ASSY
6 from CN801 on GAME board
5 from deck B head
CN508
CN509
7 from deck A head
8 from CN802 on
GAME board
1 two wires
(flat type)
3 screw (BVTP3 x 10)
4 fcrew (BVTP3 x 10
)
MAIN board
4 CD mechanism deck
2 wire (flat type) (27 core)
1 two screws (BVTP3 x 10
)
3 CN701
MAIN board
CN201
