Sony HCD-GNX70 - Electrical Parts List: Panel Board Components (Continued); Panel Board Capacitor and Connector Listings

69
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-GNX60/GNX70/GX9900
MIC MOTOR (LD) MOTOR (TB) PA
< IC >
IC1100 8-759-710-97 IC NJM4565M-D
IC1101 8-759-496-41 IC M65850FP-E1
< JACK >
J1100 1-817-629-11 JACK (LARGE TYPE) (MIC 1)
J1101 1-817-629-11 JACK (LARGE TYPE) (MIC 2)
J1103 1-794-702-11 JACK, HEADPHONE (PHONES)
< JUMPER RESISTOR >
JR1101 1-216-864-11 SHORT CHIP 0
JR1102 1-216-864-11 SHORT CHIP 0
JR1103 1-216-296-11 SHORT CHIP 0
JR1104 1-216-296-11 SHORT CHIP 0
JR1105 1-216-296-11 SHORT CHIP 0
JR1106 1-216-864-11 SHORT CHIP 0
JR1108 1-216-864-11 SHORT CHIP 0
JR1113 1-216-296-11 SHORT CHIP 0
JR1114 1-216-296-11 SHORT CHIP 0
< RESISTOR >
R1100 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1101 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1102 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1103 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1104 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1105 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1106 1-216-841-11 METAL CHIP 47K 5% 1/10W
R1107 1-216-809-11 METAL CHIP 100 5% 1/10W
R1108 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1109 1-216-847-11 METAL CHIP 150K 5% 1/10W
R1110 1-216-809-11 METAL CHIP 100 5% 1/10W
R1111 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1113 1-216-835-11 METAL CHIP 15K 5% 1/10W
R1114 1-216-835-11 METAL CHIP 15K 5% 1/10W
R1115 1-216-815-11 METAL CHIP 330 5% 1/10W
R1116 1-216-815-11 METAL CHIP 330 5% 1/10W
R1117 1-216-835-11 METAL CHIP 15K 5% 1/10W
R1118 1-216-835-11 METAL CHIP 15K 5% 1/10W
R1119 1-216-835-11 METAL CHIP 15K 5% 1/10W
R1120 1-216-846-11 METAL CHIP 120K 5% 1/10W
R1121 1-216-835-11 METAL CHIP 15K 5% 1/10W
R1122 1-216-835-11 METAL CHIP 15K 5% 1/10W
R1123 1-216-835-11 METAL CHIP 15K 5% 1/10W
R1124 1-216-841-11 METAL CHIP 47K 5% 1/10W
R1125 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1126 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1132 1-216-864-11 SHORT CHIP 0
< VARIABLE RESISTOR >
RV1100 1-227-452-11 RES, VAR, CARBON 50K (MIC LEVEL)
RV1101 1-227-452-11 RES, VAR, CARBON 50K (ECHOLEVEL)
*************************************************************
1-687-133-12 MOTOR (LD) BOARD
*****************
*************************************************************
1-687-134-12 MOTOR (TB) BOARD
*****************
< CONNECTOR >
CN742 1-784-727-11 CONNECTOR, FFC 5P
*************************************************************
A-1089-504-A PA BOARD, COMPLETE (GNX60: E3, AUS)
A-1089-530-A PA BOARD, COMPLETE (GNX70: E3, AUS)
A-1089-586-A PA BOARD, COMPLETE (GX9900)
A-1110-893-A PA BOARD, COMPLETE (GNX60: E2, E51, AR)
A-1110-912-A PA BOARD, COMPLETE (GNX70: E2, E51)
*******************
< CAPACITOR >
C600 1-126-963-11 ELECT 4.7uF 20% 50V
C601 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C602 1-104-658-91 ELECT 100uF 20% 10V
C604 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C605 1-131-992-91 CERAMIC CHIP 0.1uF 35V
C606 1-131-992-91 CERAMIC CHIP 0.1uF 35V
C608 1-126-965-91 ELECT 22uF 20% 50V
C609 1-128-560-11 ELECT 22uF 20% 100V
C610 1-128-560-11 ELECT 22uF 20% 100V
C616 1-136-495-11 FILM 0.068uF 5% 50V
C617 1-136-495-11 FILM 0.068uF 5% 50V
C618 1-128-582-11 ELECT 10uF 20% 100V
C619 1-128-582-11 ELECT 10uF 20% 100V
C634 1-104-665-11 ELECT 100uF 20% 25V
C635 1-104-665-11 ELECT 100uF 20% 25V
C636 1-107-721-11 ELECT 4.7uF 20% 100V
C637 1-107-721-11 ELECT 4.7uF 20% 100V
C648 1-104-658-91 ELECT 100uF 20% 10V
C649 1-126-964-11 ELECT 10uF 20% 50V
C650 1-126-963-11 ELECT 4.7uF 20% 50V
C651 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C652 1-104-658-91 ELECT 100uF 20% 10V
C654 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C655 1-126-964-11 ELECT 10uF 20% 50V
C656 1-127-815-11 ELECT 3300uF 20% 100V
C658 1-127-811-11 ELECT 3300uF 20% 50V
C660 1-131-992-91 CERAMIC CHIP 100000PF 35V
C666 1-136-495-11 FILM 0.068uF 5% 50V
C667 1-136-495-11 FILM 0.068uF 5% 50V
C676 1-127-815-11 ELECT 3300uF 20% 100V
C678 1-127-811-11 ELECT 3300uF 20% 50V
C681 1-110-563-11 CERAMIC CHIP 0.068uF 10% 16V
C682 1-110-563-11 CERAMIC CHIP 0.068uF 10% 16V
C683 1-131-992-91 CERAMIC CHIP 0.1uF 35V
C691 1-110-563-11 CERAMIC CHIP 0.068uF 10% 16V
C692 1-110-563-11 CERAMIC CHIP 0.068uF 10% 16V
C693 1-131-992-91 CERAMIC CHIP 0.1uF 35V
< CONNECTOR >
CN600 1-764-865-41 CONNECTOR, BOARD TO BOARD 13P
CN601 1-784-031-41 CONNECTOR, BOARD TO BOARD 8P
Ver. 1.1
