Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-GNX60/GNX70/GX9900
PA
< DIODE >
D609 8-719-988-61 DIODE 1SS355TE-17
D611 8-719-056-93 DIODE UDZ-TE-17-18B
D612 8-719-056-93 DIODE UDZ-TE-17-18B
D620 8-719-988-61 DIODE 1SS355TE-17
D624 8-719-988-61 DIODE 1SS355TE-17
D646 8-719-988-61 DIODE 1SS355TE-17
D654 8-719-988-61 DIODE 1SS355TE-17
D655 8-719-988-61 DIODE 1SS355TE-17
D656 8-719-500-60 DIODE D5SBA20
D658 8-719-500-60 DIODE D5SBA20
D660 8-719-988-61 DIODE 1SS355TE-17
D661 8-719-988-61 DIODE 1SS355TE-17
D665 8-719-988-61 DIODE 1SS355TE-17 (GNX70/GX9900)
D670 8-719-988-61 DIODE 1SS355TE-17
< IC >
IC600 8-749-017-06 IC STK412-150
< JUMPER RESISTOR >
JR600 1-216-296-11 SHORT CHIP 0
JR603 1-216-296-11 SHORT CHIP 0
< TRANSISTOR >
Q604 8-729-924-99 TRANSISTOR 2SC3722K-E
Q606 8-729-821-00 TRANSISTOR 2SA1207
Q610 8-729-924-99 TRANSISTOR 2SC3722K-E
Q618 8-729-924-99 TRANSISTOR 2SC3722K-E
Q628 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q629 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q630 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q634 8-729-027-31 TRANSISTOR DTA124EKA-T146
Q640 8-729-802-80 TRANSISTOR 2SC3661
Q641 8-729-802-80 TRANSISTOR 2SC3661
Q644 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q647 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q648 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q666 8-729-120-28 TRANSISTOR 2SC1623-L5L6
(GNX70/GX9900)
Q668 8-729-924-99 TRANSISTOR 2SC3722K-E
Q682 8-729-120-28 TRANSISTOR 2SC1623-L5L6
< RESISTOR >
R600 1-216-821-11 METAL CHIP 1K 5% 1/10W
R601 1-216-841-11 METAL CHIP 47K 5% 1/10W
R602 1-216-817-11 METAL CHIP 470 5% 1/10W
(GNX70/GX9900)
R602 1-216-818-11 METAL CHIP 560 5% 1/10W
(GNX60)
R603 1-216-841-11 METAL CHIP 47K 5% 1/10W
R604 1-216-833-11 METAL CHIP 10K 5% 1/10W
R605 1-216-833-11 METAL CHIP 10K 5% 1/10W
R606 1-216-841-11 METAL CHIP 47K 5% 1/10W
R607 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R608 1-216-845-11 METAL CHIP 100K 5% 1/10W
R609 1-216-843-11 METAL CHIP 68K 5% 1/10W
R610 1-216-843-11 METAL CHIP 68K 5% 1/10W
R611 1-216-839-11 METAL CHIP 33K 5% 1/10W
0R612 1-245-605-51 FUSIBLE 100 5% 1/4W
R613 1-215-872-11 METAL OXIDE 3.3K 5% 1W
R614 1-215-872-11 METAL OXIDE 3.3K 5% 1W
0R615 1-245-605-51 FUSIBLE 100 5% 1/4W
0R616 1-217-637-00 FUSIBLE 1 5% 1/4W
R617 1-216-845-11 METAL CHIP 100K 5% 1/10W
0R618 1-234-798-11 ENCAPSULATED COMPONENT
R619 1-216-821-11 METAL CHIP 1K 5% 1/10W
R620 1-216-839-11 METAL CHIP 33K 5% 1/10W
R621 1-216-845-11 METAL CHIP 100K 5% 1/10W
R622 1-245-711-31 CARBON 10 5% 1/2W
R623 1-216-843-11 METAL CHIP 68K 5% 1/10W
R624 1-216-837-11 METAL CHIP 22K 5% 1/10W
R625 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
(US, E2, E51, AR)
R625 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
(GNX60: E3, AUS)
R625 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
(GNX70: E3, AUS)
R626 1-216-842-11 METAL CHIP 56K 5% 1/10W
R627 1-216-821-11 METAL CHIP 1K 5% 1/10W
R628 1-216-837-11 METAL CHIP 22K 5% 1/10W
R629 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
R630 1-216-845-11 METAL CHIP 100K 5% 1/10W
R631 1-216-845-11 METAL CHIP 100K 5% 1/10W
R632 1-216-845-11 METAL CHIP 100K 5% 1/10W
R633 1-216-842-11 METAL CHIP 56K 5% 1/10W
R634 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R635 1-216-833-11 METAL CHIP 10K 5% 1/10W
R636 1-215-891-11 METAL OXIDE 680 5% 2W
R637 1-215-891-11 METAL OXIDE 680 5% 2W
R638 1-216-845-11 METAL CHIP 100K 5% 1/10W
R639 1-216-845-11 METAL CHIP 100K 5% 1/10W
R640 1-216-821-11 METAL CHIP 1K 5% 1/10W
R641 1-216-821-11 METAL CHIP 1K 5% 1/10W
R642 1-216-811-11 METAL CHIP 150 5% 1/10W
R643 1-216-811-11 METAL CHIP 150 5% 1/10W
R644 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R645 1-216-833-11 METAL CHIP 10K 5% 1/10W
0R646 1-260-086-31 CARBON 82 5% 1/2W
R647 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R648 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R649 1-216-837-11 METAL CHIP 22K 5% 1/10W
R650 1-216-821-11 METAL CHIP 1K 5% 1/10W
R651 1-216-841-11 METAL CHIP 47K 5% 1/10W
R652 1-216-817-11 METAL CHIP 470 5% 1/10W
(GNX70/GX9900)
R652 1-216-818-11 METAL CHIP 560 5% 1/10W
(GNX60)
R653 1-216-841-11 METAL CHIP 47K 5% 1/10W
R654 1-216-841-11 METAL CHIP 47K 5% 1/10W
R655 1-216-841-11 METAL CHIP 47K 5% 1/10W
R656 1-216-849-11 METAL CHIP 220K 5% 1/10W
R657 1-216-849-11 METAL CHIP 220K 5% 1/10W
R658 1-216-845-11 METAL CHIP 100K 5% 1/10W
R660 1-216-837-11 METAL CHIP 22K 5% 1/10W
R661 1-216-837-11 METAL CHIP 22K 5% 1/10W
