Sony HCD-GNX70 - Electrical Parts List: MIC, Motor Boards; Miscellaneous Board Components

71
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-GNX60/GNX70/GX9900
PA PANEL
R662 1-216-811-11 METAL CHIP 150 5% 1/10W
R663 1-216-811-11 METAL CHIP 150 5% 1/10W
0R665 1-260-086-31 CARBON 82 5% 1/2W
(GNX70/GX9900)
R666 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(GNX70/GX9900)
R667 1-216-833-11 METAL CHIP 10K 5% 1/10W
(GNX70/GX9900)
0R668 1-234-798-11 ENCAPSULATED COMPONENT
R669 1-216-821-11 METAL CHIP 1K 5% 1/10W
R670 1-216-839-11 METAL CHIP 33K 5% 1/10W
R671 1-216-845-11 METAL CHIP 100K 5% 1/10W
R672 1-245-711-31 CARBON 10 5% 1/2W
R673 1-216-842-11 METAL CHIP 56K 5% 1/10W
R674 1-216-837-11 METAL CHIP 22K 5% 1/10W
R676 1-216-849-11 METAL CHIP 220K 5% 1/10W
R677 1-216-849-11 METAL CHIP 220K 5% 1/10W
R678 1-216-845-11 METAL CHIP 100K 5% 1/10W
R681 1-245-711-31 CARBON 10 5% 1/2W
R682 1-216-821-11 METAL CHIP 1K 5% 1/10W
R683 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R685 1-216-833-11 METAL CHIP 10K 5% 1/10W
R691 1-245-711-31 CARBON 10 5% 1/2W
R692 1-216-841-11 METAL CHIP 47K 5% 1/10W
R693 1-216-845-11 METAL CHIP 100K 5% 1/10W
R694 1-216-843-11 METAL CHIP 68K 5% 1/10W
R695 1-216-845-11 METAL CHIP 100K 5% 1/10W
R696 1-216-845-11 METAL CHIP 100K 5% 1/10W
R697 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R698 1-216-845-11 METAL CHIP 100K 5% 1/10W
< RELAY >
RY646 1-755-500-11 RELAY
RY665 1-755-500-11 RELAY (GNX70/GX9900)
< THERMISTOR >
TH629 1-807-796-11 THERMISTOR
TH630 1-807-796-11 THERMISTOR
< TERMINAL >
TM600 1-780-001-21 TERMINAL BOARD (SPEAKER)
(FRONT SPEAKER)
TM601 1-780-001-21 TERMINAL BOARD (SPEAKER)
(SURR SPEAKER) (GNX70/GX9900)
*************************************************************
A-1089-463-A PANEL BOARD, COMPLETE
**********************
< CAPACITOR >
C900 1-126-163-11 ELECT 4.7uF 20% 50V
C901 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C902 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C903 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C904 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C905 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C906 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C907 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C908 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C909 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C910 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C916 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C917 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C918 1-119-941-91 ELECT 470uF 20% 6.3V
C919 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C922 1-124-261-00 ELECT 10uF 20% 50V
C923 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C924 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C925 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C926 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C927 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C928 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C929 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C930 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C931 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C932 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C933 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C934 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C935 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C936 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C937 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C938 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C939 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C941 1-124-261-00 ELECT 10uF 20% 50V
C942 1-124-261-00 ELECT 10uF 20% 50V
C944 1-124-261-00 ELECT 10uF 20% 50V
C945 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C946 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C947 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C948 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C949 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C950 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C951 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C952 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C953 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C954 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C955 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C956 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C957 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C958 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C959 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C961 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C966 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C970 1-119-941-91 ELECT 470uF 20% 6.3V
C971 1-119-941-91 ELECT 470uF 20% 6.3V
C972 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C973 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C977 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C978 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C979 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C980 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C981 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C982 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C983 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
