— 80 —
Ref. No. Part No. Description Remark
L4 1-410-515-11 INDUCTOR 33uH (AEP,UK,G)
L41 1-407-500-00 MICRO INDUCTOR 4.7mH (AEP,UK,EE)
L41 1-410-119-11 MICRO INDUCTOR (EL TYPE) 1mH (G)
< FILTER >
LPF41 1-239-845-11 FILTER, LOW PASS
LPF42 1-239-845-11 FILTER, LOW PASS
< TRANSISTOR >
Q1 8-729-201-27 TRANSISTOR 2SC2715Y-TE85L
Q2 8-729-201-27 TRANSISTOR 2SC2715Y-TE85L
Q3 8-729-201-27 TRANSISTOR 2SC2715Y-TE85L
Q4 8-729-201-27 TRANSISTOR 2SC2715Y-TE85L
Q5 8-729-424-08 TRANSISTOR UN2111
Q9 8-729-216-22 TRANSISTOR 2SA812-M5M6 (AEP,UK,EE)
Q11 8-729-421-22 TRANSISTOR UN2211 (AEP,UK,EE)
Q12 8-729-421-22 TRANSISTOR UN2211 (AEP,UK,EE)
Q13 8-729-421-22 TRANSISTOR UN2211 (AEP,UK,EE)
Q14 8-729-421-22 TRANSISTOR UN2211 (AEP,UK,EE)
< RESISTOR >
R1 1-249-401-11 CARBON 47 5% 1/4W F
R2 1-216-037-00 METAL CHIP 330 5% 1/10W
R3 1-216-037-00 METAL CHIP 330 5% 1/10W
R5 1-216-037-00 METAL CHIP 330 5% 1/10W
R6 1-216-081-00 METAL CHIP 22K 5% 1/10W
R7 1-216-037-00 METAL CHIP 330 5% 1/10W
R8 1-216-037-00 METAL CHIP 330 5% 1/10W
R9 1-216-081-00 METAL CHIP 22K 5% 1/10W
R10 1-216-037-00 METAL CHIP 330 5% 1/10W
R11 1-216-081-00 METAL CHIP 22K 5% 1/10W
R12 1-216-037-00 METAL CHIP 330 5% 1/10W
R13 1-216-037-00 METAL CHIP 330 5% 1/10W
R14 1-216-081-00 METAL CHIP 22K 5% 1/10W
R18 1-216-073-00 METAL CHIP 10K 5% 1/10W
(AEP,UK,EE)
R19 1-216-073-00 METAL CHIP 10K 5% 1/10W
(AEP,UK,EE)
R21 1-216-049-91 METAL CHIP 1.0K 5% 1/10W
R22 1-216-049-91 METAL CHIP 1.0K 5% 1/10W
R23 1-216-049-91 METAL CHIP 1.0K 5% 1/10W
R24 1-216-025-91 METAL CHIP 100 5% 1/10W
R25 1-249-417-11 CARBON 1K 5% 1/4W F
R26 1-249-437-11 CARBON 47K 5% 1/4W
R27 1-249-429-11 CARBON 10K 5% 1/4W
R28 1-249-417-11 CARBON 1K 5% 1/4W F
R29 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R30 1-216-186-00 METAL CHIP 330 5% 1/8W
R31 1-216-025-91 METAL CHIP 100 5% 1/10W
R32 1-249-425-11 CARBON 4.7K 5% 1/4W F
R33 1-249-425-11 CARBON 4.7K 5% 1/4W F
R34 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R35 1-216-214-00 METAL CHIP 4.7K 5% 1/8W
R36 1-216-025-91 METAL CHIP 100 5% 1/10W
R37 1-216-073-00 METAL CHIP 10K 5% 1/10W
R38 1-216-089-91 METAL CHIP 47K 5% 1/10W
R39 1-249-429-11 CARBON 10K 5% 1/4W
R42 1-216-073-00 METAL CHIP 10K 5% 1/10W
R43 1-216-042-00 METAL CHIP 510 5% 1/10W
R44 1-216-013-00 METAL CHIP 33 5% 1/10W
R45 1-247-843-11 CARBON 3.3K 5% 1/4W F
R46 1-216-073-00 METAL CHIP 10K 5% 1/10W
R47 1-216-097-91 METAL CHIP 100K 5% 1/10W
R48 1-249-417-11 CARBON 1K 5% 1/4W F
R49 1-216-049-91 METAL CHIP 1.0K 5% 1/10W
R50 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R51 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R53 1-249-429-11 CARBON 10K 5% 1/4W
R55 1-216-162-00 METAL CHIP 33 5% 1/8W
R56 1-249-393-11 CARBON 10 5% 1/4W F
R91 1-216-295-11 METAL CHIP 0 5% 1/10W
(AEP,UK,EE)
R92 1-216-073-00 METAL CHIP 10K 5% 1/10W
(AEP,UK,EE)
R99 1-249-399-11 CARBON 33 5% 1/4W
< VARIABLE RESISTOR >
RV41 1-238-601-11 RES, ADJ, CARBON 22K
RV42 1-238-600-11 RES, ADJ, CARBON 10K
< TERMINAL >
TM1 1-537-488-11 TERMINAL BOARD (ANT) (ANTENNA)
< VIBRATOR >
X21 1-760-549-11 VIBRATOR, CRYSTAL (4.5MHz)
X41 1-760-220-11 FILTER, CERAMIC (10.7MHz)
X42 1-527-981-00 FILTER, CERAMIC (450KHz)
X43 1-577-075-11 OSCILLATOR, CERAMIC (456KHz)
**************************************************************
* 1-664-649-11 TRANSFORMER BOARD
*******************
1-533-233-21 HOLDER, FUSE
< CONNECTOR >
CN1601 1-564-321-00 PIN, CONNECTOR 2P
CN1602 1-691-771-11 PLUG (MICRO CONNECTOR) 9P
< FUSE >
! F1601 1-532-504-31 FUSE, TIME-LAG (4A/250V)
(GR3/RX30:AEP,UK,G,EE)
! F1601 1-533-420-11 FUSE, GLASS CYLINDRICAL(DIA.5)(5A/125V)
(RX30:US,CND)
! F1602 1-532-504-31 FUSE, TIME-LAG (4A/250V)
(GR3/RX30:AEP,UK,G,EE)
! F1602 1-533-420-11 FUSE, GLASS CYLINDRICAL(DIA.5)(5A/125V)
(RX30:US,CND)
< RESISTOR >
! R1600 1-202-725-00 SOLID 3.3M 10% 1/2W
(RX30:US,CND)
! R1601 1-217-637-00 FUSIBLE 1 5% 1/4W F
! R1602 1-219-121-11 FUSIBLE 0.22 5% 1/4W F
! R1603 1-219-121-11 FUSIBLE 0.22 5% 1/4W F
Ref. No. Part No. Description Remark
TCB
TRANSFORMER
Les composants identifiés par
une marque ! sont critiques pour
la sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
