— 81 —
Ref. No. Part No. Description Remark
< SWITCH >
! S1601 1-572-675-11 SWITCH, POWER VOLTAGE CHANGE
(VOLTAGE SELECTOR)(GR3:E,AR)
< TRANSFORMER >
! T1001 1-431-127-11 TRANSFORMER, POWER (GR3)
! T1001 1-431-128-11 TRANSFORMER, POWER (RX30:US,CND)
! T1001 1-431-129-11 TRANSFORMER, POWER (RX30:AEP,UK,G,EE)
**************************************************************
MISCELLANEOUS
*************
2 1-233-544-11 ENCAPSULATED COMPONENT (RX30:US,CND)
2 1-233-545-11 ENCAPSULATED COMPONENT
(GR3:EXCEPT SAF)
2 1-233-546-11 ENCAPSULATED COMPONENT (GR3:SAF)
3 1-769-977-11 WIRE (FLAT TYPE)(13 CORE)(GR3:SAF)
3 1-782-079-11 WIRE (FLAT TYPE)(13 CORE)
(GR3:EXCEPT SAF/RX30:US,CND)
3 1-782-081-11 WIRE (FLAT TYPE)(15 CORE)(RX30:AEP,UK,G,EE)
6 1-773-020-11 WIRE (FLAT TYPE)(15 CORE)(SAF)
6 1-782-082-11 WIRE (FLAT TYPE)(15 CORE)(EXCEPT SAF)
7 1-776-240-11 WIRE (FLAT TYPE)(19 CORE)
257 1-452-538-11 MAGNET
258 1-776-042-11 WIRE (FLAT TYPE) (8 CORE)
! 301 8-848-367-11 OPTICAL PICK-UP KSS-213B/K-N
302 1-769-069-11 WIRE (FLAT TYPE) (16 CORE)
451 1-500-322-11 HEAD, WIRE (E)
453 1-500-319-11 HEAD, HOLDER (DECK B)
455 1-500-320-11 HEAD, WIRE R/P (DECK B)
456 1-500-321-11 HEAD, WIRE P.B (DECK A)
514 1-762-610-11 SWITCH, PLATE
515 1-762-613-11 SWITCH, WIRE LEAF
516 1-762-612-11 SWITCH, WIRE LEAF
! CNP1601 1-782-315-11 CORD, POWER (E,MX)
! CNP1601 1-690-608-11 CORD, POWER (AUS)
! CNP1601 1-690-609-21 CORD, POWER (CND)
! CNP1601 1-777-070-11 CORD, POWER (US)
! CNP1601 1-777-071-11 CORD, POWER (AEP,G,EE,AR)
! CNP1601 1-575-651-11 CORD, POWER (SAF)
! CNP1601 1-777-512-11 CORD, POWER (UK)
FL501 1-517-660-11 INDICATOR TUBE, FLUORESCENT
HE901 1-500-318-11 HEAD, E (ERASE)(DECK B)
HP901 1-543-424-21 HEAD (PLAYBACK)(DECK A)
HRP901 1-543-424-21 HEAD (RECORD/PLAYBACK)(DECK B)
M101 X-4917-523-4 MOTOR ASSY (SPINDLE)
M102 X-4917-504-1 MOTOR ASSY (SLED)
M701 A-4672-004-A MOTOR ASSY (TURN)
M801 A-4672-004-A MOTOR ASSY (SLIDE)
M901 X-3372-231-1 MOTOR ASSY (REEL/CAPSTAN)
S1 1-571-556-11 SWITCH, LEAF (MOTOR)(DECK A)
S2 1-571-745-11 SWITCH, LEAF (PLAY)(DECK A)
S3 1-762-611-11 SWITCH, LEAF (TYPE 2)(DECK A)
S4 1-571-556-11 SWITCH, LEAF (MOTOR)(DECK B)
S5 1-571-745-11 SWITCH, LEAF (PLAY)(DECK B)
S6 1-762-611-11 SWITCH, LEAF (TYPE 2)(DECK B)
S7 1-571-556-11 SWITCH, LEAF (REC)(DECK B)
Ref. No. Part No. Description Remark
S811 1-473-335-11 ENCODER, ROTARY (BU, TRAY ADDRESS DET)
! T1001 1-431-127-11 TRANSFORMER, POWER (GR3)
! T1001 1-431-128-11 TRANSFORMER, POWER (RX30:US,CND)
! T1001 1-431-129-11 TRANSFORMER, POWER (RX30:AEP,UK,G,EE)
**************************************************************
ACCESSORIES & PACKING MATERIALS
*******************************
1-501-374-11 ANTENNA, LOOP (SAF)
1-501-659-11 ANTENNA (FM)(SAF)
3-859-826-11 MANUAL, INSTRUCTION
(ENGLISH,FRENCH,SPANISH)(SAF)
4-979-371-01 COVER, BATTERY (for RM-SD25)
8-917-538-90 REMOCON RM-SD25//M SET (SAF)
**************************************************************
**************
HARDWARE LIST
**************
#1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#2 7-685-872-09 SCREW +BVTT 3X8 (S)
#3 7-685-650-79 SCREW +BVTP 3X16 TYPE2 IT-3
#4 7-685-791-09 SCREW +PTT 2.6X5 (S)
#5 7-621-255-15 SCREW +P 2X3
#6 7-685-782-01 SCREW +PTT 2X5 (S)
#7 7-621-773-86 SCRTEWTOTSU PTTWH 2.6X4
#8 7-685-781-09 SCREW +PTT 2X4 (S)
#9 7-685-104-19 SCREW +P 2X6 TYPE2 NON-SLIT
#10 7-621-775-10 SCREW +B 2.6X4
TRANSFORMER
Les composants identifiés par
une marque ! sont critiques pour
la sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
