Sony HCD-GR5 - Page 56

— 84 —
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
The components identified by
mark ! or dotted line with mark !
are critical for safety.
Replace only with part number
specified.
MAIN
* CN702 1-568-830-11 SOCKET, CONNECTOR 11P
* CN703 1-568-834-11 SOCKET, CONNECTOR 15P (EXCEPT EA4,TH)
* CN703 1-568-832-11 SOCKET, CONNECTOR 13P (EA4,TH)
< DIODE >
D201 8-719-987-63 DIODE 1N4148M
D202 8-719-987-63 DIODE 1N4148M
D205 8-719-010-33 DIODE UZ-4.7BSB
D401 8-719-933-54 DIODE HZS9A2L
D701 8-719-987-63 DIODE 1N4148M
D702 8-719-987-63 DIODE 1N4148M
D703 8-719-987-63 DIODE 1N4148M
D704 8-719-987-63 DIODE 1N4148M
D705 8-719-987-63 DIODE 1N4148M
D706 8-719-024-99 DIODE 11ES2-NTA2B
D707 8-719-987-63 DIODE 1N4148M
D708 8-719-987-63 DIODE 1N4148M
D1001 8-719-024-99 DIODE 11ES2-NTA2B
D1003 8-719-024-99 DIODE 11ES2-NTA2B
D1004 8-719-024-99 DIODE 11ES2-NTA2B
D1005 8-719-024-99 DIODE 11ES2-NTA2B
D1006 8-719-024-99 DIODE 11ES2-NTA2B
D1007 8-719-987-63 DIODE 1N4148M
D1008 8-719-001-42 DIODE UZL-11M1
D1009 8-719-987-63 DIODE 1N4148M
D1010 8-719-987-63 DIODE 1N4148M
D1011 8-719-011-54 DIOD UZ-4.3BS-TA
D1013 8-719-024-99 DIODE 11ES2-NTA2B
D1014 8-719-024-99 DIODE 11ES2-NTA2B
D1016 8-719-024-99 DIODE 11ES2-NTA2B
D1017 8-719-024-99 DIODE 11ES2-NTA2B
D1018 8-719-024-99 DIODE 11ES2-NTA2B
D1021 8-719-024-99 DIODE 11ES2-NTA2B
D1022 8-719-024-99 DIODE 11ES2-NTA2B
D1023 8-719-011-05 DIODE UZ-27BS
D1059 8-719-987-63 DIODE 1N4148M
D1069 8-719-987-63 DIODE 1N4148M
D1095 8-719-987-63 DIODE 1N4148M
D1096 8-719-987-63 DIODE 1N4148M
D1097 8-719-024-99 DIODE 11ES2-NTA2B
D1098 8-719-024-99 DIODE 11ES2-NTA2B
D1099 8-719-024-99 DIODE 11ES2-NTA2B
D1201 8-719-987-63 DIODE 1N4148M
D1202 8-719-987-63 DIODE 1N4148M
D1204 8-719-987-63 DIODE 1N4148M
D1205 8-719-987-63 DIODE 1N4148M
D1230 8-719-987-63 DIODE 1N4148M
D1250 8-719-028-23 DIODE D3SBA20-4101
D1251 8-719-987-63 DIODE 1N4148M
D1309 8-719-987-63 DIODE 1N4148M
D1310 8-719-987-63 DIODE 1N4148M
< FUSE >
! F1601 1-532-504-31 FUSE,TIME-LAG (4A / 250V)
! F1602 1-532-504-31 FUSE,TIME-LAG (4A / 250V)
< IC >
IC200 8-749-923-04 IC TOTX178 (CD DIGITAL OUT OPTICAL)
IC201 8-759-822-09 IC LB1641
IC401 8-759-289-38 IC HA12195NT
IC402 8-759-822-09 IC LB1641
IC701 8-759-451-82 IC TMP87CS64YF-6521
IC702 8-759-165-80 IC PST600C-T
IC802 8-759-000-48 IC MC14052BCP
IC901 8-759-331-39 IC M62427FP
IC1001 8-759-231-53 IC TA7805S
IC1002 8-759-604-86 IC M5F7807L
IC1003 8-759-604-86 IC M5F7807L
IC1004 8-759-604-90 IC M5F7907L
IC1201 8-749-920-09 IC STK-4152MK2K
IC1202 8-759-111-68 IC uPC1237HA
< JACK >
J801 1-695-188-31 JACK, PIN 4P (MD AUDIO IN,OUT)
J1201 1-774-785-11 JACK, PIN 1P (SUPER WOOFER)
(EXCEPT AEP,UK,G,EE)
< COIL >
L1201 1-420-872-00 COIL, AIR-CORE (AEP,UK,G,EE)
L1251 1-420-872-00 COIL, AIR-CORE (AEP,UK,G,EE)
< TRANSISTOR >
Q301 8-729-119-78 TRANSISTOR 2SC403SP-51
Q351 8-729-119-78 TRANSISTOR 2SC403SP-51
Q401 8-729-119-78 TRANSISTOR 2SC403SP-51
Q402 8-729-900-65 TRANSISTOR DTA144ES
Q403 8-729-801-93 TRANSISTOR 2SD1387
Q406 8-729-900-80 TRANSISTOR DTC114ES
Q407 8-729-422-57 TRANSISTOR UN4111
Q408 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q409 8-729-900-80 TRANSISTOR DTC114ES
Q410 8-729-900-65 TRANSISTOR DTA144ES
Q411 8-729-900-65 TRANSISTOR DTA144ES
Q412 8-729-900-65 TRANSISTOR DTA144ES
Q701 8-729-119-78 TRANSISTOR 2SC403SP-51
Q820 8-729-422-57 TRANSISTOR UN4111
Q901 8-729-119-78 TRANSISTOR 2SC403SP-51
Q902 8-729-119-78 TRANSISTOR 2SC403SP-51
Q951 8-729-119-78 TRANSISTOR 2SC403SP-51
Q952 8-729-119-78 TRANSISTOR 2SC403SP-51
Q953 8-729-141-26 TRANSISTOR 2SC3622A-LK
Q954 8-729-141-26 TRANSISTOR 2SC3622A-LK
Q1001 8-729-118-01 TRANSISTOR 2SB1116
Q1002 8-729-900-36 TRANSISTOR DTC124ES
Q1003 8-729-021-82 TRANSISTOR 2SD2396K
Q1006 8-729-030-19 TRANSISTOR 2SB1640
Q1201 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q1204 8-729-900-63 TRANSISTOR DTA124ES
Q1205 8-729-900-36 TRANSISTOR DTC124ES
Q1206 8-729-900-80 TRANSISTOR DTC114ES
Q1207 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q1208 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q1251 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
