— 87 —
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
The components identified by
mark ! or dotted line with mark !
are critical for safety.
Replace only with part number
specified.
PANEL
R1258 1-249-425-11 CARBON 4.7K 5% 1/4W
!R1259 1-212-881-11 FUSIBLE 100 5% 1/4W F
!R1260 1-208-602-11 WIREWOUND 0.22 10% 2W F
R1261 1-249-417-11 CARBON 1K 5% 1/4W
R1262 1-249-431-11 CARBON 15K 5% 1/4W
R1263 1-249-441-11 CARBON 100K 5% 1/4W
R1264 1-249-429-11 CARBON 10K 5% 1/4W
R1265 1-249-429-11 CARBON 10K 5% 1/4W
R1266 1-249-429-11 CARBON 10K 5% 1/4W
R1267 1-249-429-11 CARBON 10K 5% 1/4W
R1268 1-249-397-11 CARBON 22 5% 1/4W
R1269 1-249-397-11 CARBON 22 5% 1/4W
R1270 1-249-389-11 CARBON 4.7 5% 1/4W
(AEP,UK,G,EE)
R1271 1-249-389-11 CARBON 4.7 5% 1/4W
(AEP,UK,G,EE)
R1272 1-249-409-11 CARBON 220 5% 1/4W
R1273 1-249-409-11 CARBON 220 5% 1/4W
R1281 1-249-439-11 CARBON 68K 5% 1/4W
(EXCEPT AEP,UK,G,EE)
R1290 1-249-437-11 CARBON 47K 5% 1/4W
R1295 1-249-433-11 CARBON 22K 5% 1/4W
R1296 1-249-421-11 CARBON 2.2K 5% 1/4W
(EXCEPT AEP,UK,G,EE)
R1299 1-249-389-11 CARBON 4.7 5% 1/4W
(AEP,UK,G,EE)
R1303 1-249-427-11 CARBON 6.8K 5% 1/4W
R1304 1-249-427-11 CARBON 6.8K 5% 1/4W
!R1601 1-219-124-11 FUSIBLE 0.68 5% 1/4W F
!R1602 1-219-121-11 FUSIBLE 0.22 5% 1/4W F
!R1603 1-219-121-11 FUSIBLE 0.22 5% 1/4W F
< VARIABLE RESISTOR >
RV301 1-238-600-11 RES, ADJ, CARBON 10K
RV351 1-238-600-11 RES, ADJ, CARBON 10K
< RELAY >
RY1201 1-515-920-11 RELAY (24V)
< TERMINAL >
TM1201 1-537-240-31 TERMINAL BOARD (CHECKER PIN)(SPEAKER)
(EXCEPT AEP,UK,G,EE)
TM1201 1-537-801-11 TERMINAL BOARD (SPEAKER) (AEP,UK,G,EE)
< VIBRATOR >
X701 1-579-175-11 VIBRATOR, CERAMIC (10MHz)
X702 1-567-098-41 VIBRATOR, CRYSTAL (32.768KHz)
************************************************************
* A-4392-573-A PANEL BOARD, COMPLETE (RX50)
* A-4392-581-A PANEL BOARD, COMPLETE
(E,EA3,MY,SP,HK,TW,JE)
* A-4392-589-A PANEL BOARD, COMPLETE (IA)
* A-4392-595-A PANEL BOARD, COMPLETE (EA4,TH)
*******************************
* 4-978-168-01 HOLDER, FL TUBE (EA4,TH,IA)
* 4-978-168-11 HOLDER, FL TUBE (EXCEPT EA4,TH,IA)
* 4-932-810-11 CUSHION (FL)
< CAPACITOR >
C513 1-162-294-31 CERAMIC 0.001uF 10% 50V
C514 1-124-589-11 ELECT 47uF 20% 16V
C515 1-164-159-11 CERAMIC 0.1uF 50V
C522 1-162-306-11 CERAMIC 0.01uF 20% 16V
C530 1-124-261-00 ELECT 10uF 20% 50V
C531 1-124-261-00 ELECT 10uF 20% 50V
C532 1-164-159-11 CERAMIC 0.1uF 50V
(AEP,UK,G,EE)
< CONNECTOR >
* CN501 1-568-854-11 SOCKET, CONNECTOR 11P
< DIODE >
D579 8-719-058-03 DIODE SEL5423E-TP15 (TUNER/BAND)
(EXCEPT EA4,TH)
D579 8-719-062-86 DIODE SEL5420 (TUNER/BAND) (EA4,TH)
D580 8-719-812-44 DIODE TLO124 (EFFECT ON/OFF)
D581 8-719-033-06 DIODE SEL5920A (GROOVE)
D583 8-719-056-12 DIODE SML79420C-TP4 (fl)
(EXCEPT EA4,TH,IA)
D583 8-719-056-13 DIODE SML79423C-TP15 (fl) (EA4,TH,IA)
D585 8-719-033-06 DIODE SEL5920A (P PAUSE)
D586 8-719-812-44 DIODE TLO124 (r REC)
D587 8-719-058-03 DIODE SEL5423E-TP15 (· ) (EXCEPT EA4,TH)
D587 8-719-032-86 DIODE SEL5420E (·) (EA4,TH)
D588 8-719-058-03 DIODE SEL5423E-TP15 (ª) (EXCEPT EA4,TH)
D588 8-719-032-86 DIODE SEL5420E (ª) (EA4,TH)
D589 8-719-058-03 DIODE SEL5423E-TP15 (·) (EXCEPT EA4,TH)
D589 8-719-032-86 DIODE SEL5420E (·) (EA4,TH)
D590 8-719-058-03 DIODE SEL5423E-TP15 (ª) (EXCEPT EA4,TH)
D590 8-719-032-86 DIODE SEL5420E (ª) (EA4,TH)
D601 8-719-033-06 DIODE SEL5920A (CD)
D611 8-719-033-06 DIODE SEL5920A (TUNER)
D621 8-719-033-06 DIODE SEL5920A (TIMER)
< FILTER >
FL501 1-517-489-11 INDICATOR TUBE, FLUORESCENT (EA4,TH,IA)
FL501 1-517-660-11 INDICATOR TUBE, FLUORESCENT
(EXCEPT EA4,TH,IA)
< IC >
IC501 8-759-448-36 IC uPD78042FGF-027-3B9
IC502 8-759-332-18 IC GP1U27XB
< COIL >
* L510 1-410-858-21 INDUCTOR 0uH (AEP,UK,G,EE)
< TRANSISTOR >
Q501 8-729-119-78 TRANSISTOR 2SC403SP-51
Q502 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q503 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q504 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q507 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q508 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q509 8-729-119-76 TRANSISTOR 2SA1175-HFE
MAIN
To Next Page
