HCD-GS10/GS30DAB
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
CF802 1-795-426-11 FILTER, CERAMIC (AEP, RU, SP)
CF803 1-781-962-21 FILTER, CERAMIC
< CONNECTOR >
CN103 1-819-131-11 PIN, CONNECTOR 3P
CN104 1-815-444-11 PIN, CONNECTOR (PWB) 3P
CN105 1-815-446-11 PIN, CONNECTOR (PWB) 5P
CN114 1-779-289-11 CONNECTOR, FFC (LIF (NON-ZIF)) 21P
CN121 1-779-293-11 CONNECTOR, FFC (LIF (NON-ZIF)) 25P
CN201 1-819-133-11 PIN, CONNECTOR
CN202 1-815-447-11 PIN, CONNECTOR (PWB) 6P
* CN802 1-506-680-11 PLUG, CONNECTOR (2.5mm) 3P (ANTENNA)
CN901 1-819-131-11 PIN, CONNECTOR 3P
< DIODE >
D107 6-501-583-01 DIODE 1N5401-003
D108 6-501-583-01 DIODE 1N5401-003
D109 6-501-583-01 DIODE 1N5401-003
D110 6-501-583-01 DIODE 1N5401-003
D111 6-501-584-11 DIODE 1N4002
D112 6-501-584-11 DIODE 1N4002
D131 6-501-584-11 DIODE 1N4002
D132 6-500-334-01 DIODE MC2836-T112-1
D154 6-500-335-01 DIODE MC2838-T112-1
D156 6-500-334-01 DIODE MC2836-T112-1
D191 6-501-584-11 DIODE 1N4002
D192 6-501-584-11 DIODE 1N4002
D193 6-501-193-01 DIODE 1SS355WTE-17
D471 6-501-579-01 DIODE MC2837
D802 6-501-369-01 DIODE SVC230-TB-E
D803 6-501-369-01 DIODE SVC230-TB-E
D812 6-501-579-01 DIODE MC2837
D813 6-501-579-01 DIODE MC2837
D815 6-501-193-01 DIODE 1SS355WTE-17
D851 6-501-142-01 DIODE SVC347A-TL-E
D901 6-500-335-01 DIODE MC2838-T112-1
< EARTH TERMINAL >
EP102 1-537-771-21 TERMINAL BOARD, GROUND
< IC >
IC103 6-702-771-01 IC TA78033LS
IC401 6-710-289-01 IC R2S15904SP
IC801 6-708-840-01 IC LV23003VA
< JACK >
J101 1-536-708-81 TERMINAL BOARD, PUSH (4P) (SPEAKER)
< JUMPER RESISTOR >
JR101 1-216-864-11 SHORT CHIP 0
JR102 1-216-864-11 SHORT CHIP 0
JR103 1-216-864-11 SHORT CHIP 0
JR104 1-216-864-11 SHORT CHIP 0
JR105 1-216-864-11 SHORT CHIP 0
JR106 1-216-864-11 SHORT CHIP 0
JR107 1-216-864-11 SHORT CHIP 0
JR401 1-216-864-11 SHORT CHIP 0
JR801 1-216-864-11 SHORT CHIP 0
JR802 1-216-864-11 SHORT CHIP 0
JR803 1-216-864-11 SHORT CHIP 0
JR804 1-216-864-11 SHORT CHIP 0
JR852 1-216-864-11 SHORT CHIP 0
JR853 1-216-864-11 SHORT CHIP 0
JR901 1-216-864-11 SHORT CHIP 0
< COIL >
L101 1-456-107-11 COIL, AIR-CORE
L102 1-456-107-11 COIL, AIR-CORE
L803 1-433-741-11 TRANSFORMER, IF
L804 1-457-163-11 COIL, AIR-CORE
L805 1-457-162-11 COIL, AIR-CORE
L806 1-457-168-11 COIL, DET
L851 1-457-161-11 COIL, AM ANTENNA
L853 1-410-522-11 INDUCTOR 120uH
< TRANSISTOR >
Q102 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q121 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q122 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q131 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q132 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q133 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q134 1-801-806-11 TRANSISTOR DTC144EKA
Q135 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q137 8-729-600-22 TRANSISTOR 2SA1235-F
Q138 8-729-600-22 TRANSISTOR 2SA1235-F
Q141 6-550-889-01 TRANSISTOR 2SC5938-T112-1B
Q142 6-550-889-01 TRANSISTOR 2SC5938-T112-1B
Q151 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q152 8-729-600-22 TRANSISTOR 2SA1235-F
Q153 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q191 8-729-037-13 TRANSISTOR KTA1271Y
Q193 8-729-600-22 TRANSISTOR 2SA1235-F
Q194 1-801-806-11 TRANSISTOR DTC144EKA
Q471 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q472 8-729-024-43 TRANSISTOR 2SA1365-T112-1EF
Q801 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q802 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q803 8-729-601-58 TRANSISTOR 2SC3053-C
Q901 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q902 8-729-037-03 TRANSISTOR KTA1266GR-AT
Q903 8-729-120-28 TRANSISTOR 2SC1623-L5L6
< RESISTOR >
R101 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R103 1-216-841-11 METAL CHIP 47K 5% 1/10W
R104 1-216-841-11 METAL CHIP 47K 5% 1/10W
R105 1-216-841-11 METAL CHIP 47K 5% 1/10W
R106 1-216-837-11 METAL CHIP 22K 5% 1/10W
R107 1-216-837-11 METAL CHIP 22K 5% 1/10W
R108 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R109 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R110 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R111 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R112 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R113 1-216-833-11 METAL CHIP 10K 5% 1/10W
R114 1-216-833-11 METAL CHIP 10K 5% 1/10W
R115 1-216-837-11 METAL CHIP 22K 5% 1/10W
R116 1-216-837-11 METAL CHIP 22K 5% 1/10W
R117 1-216-797-11 METAL CHIP 10 5% 1/10W
R118 1-216-797-11 METAL CHIP 10 5% 1/10W
