50
HCD-GS10/GS30DAB
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN PANEL
R805 1-216-845-11 METAL CHIP 100K 5% 1/10W
R806 1-216-864-11 SHORT CHIP 0
R807 1-216-845-11 METAL CHIP 100K 5% 1/10W
R808 1-216-833-11 METAL CHIP 10K 5% 1/10W
R809 1-216-821-11 METAL CHIP 1K 5% 1/10W
R811 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R813 1-216-833-11 METAL CHIP 10K 5% 1/10W
R814 1-216-809-11 METAL CHIP 100 5% 1/10W
R815 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R816 1-216-833-11 METAL CHIP 10K 5% 1/10W
R817 1-216-833-11 METAL CHIP 10K 5% 1/10W
R818 1-216-841-11 METAL CHIP 47K 5% 1/10W
R819 1-216-841-11 METAL CHIP 47K 5% 1/10W
R820 1-216-833-11 METAL CHIP 10K 5% 1/10W
R821 1-216-813-11 METAL CHIP 220 5% 1/10W
R822 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R823 1-216-809-11 METAL CHIP 100 5% 1/10W
R824 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R825 1-216-817-11 METAL CHIP 470 5% 1/10W
R826 1-216-809-11 METAL CHIP 100 5% 1/10W
R827 1-216-809-11 METAL CHIP 100 5% 1/10W
R828 1-216-801-11 METAL CHIP 22 5% 1/10W
(AEP, RU, SP)
R828 1-216-805-11 METAL CHIP 47 5% 1/10W
(E2, AR)
R829 1-216-845-11 METAL CHIP 100K 5% 1/10W
R830 1-216-841-11 METAL CHIP 47K 5% 1/10W
R831 1-216-813-11 METAL CHIP 220 5% 1/10W
R833 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R834 1-216-837-11 METAL CHIP 22K 5% 1/10W
R835 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R837 1-216-821-11 METAL CHIP 1K 5% 1/10W
R838 1-216-821-11 METAL CHIP 1K 5% 1/10W
R839 1-216-809-11 METAL CHIP 100 5% 1/10W
R840 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R841 1-216-809-11 METAL CHIP 100 5% 1/10W
R842 1-216-841-11 METAL CHIP 47K 5% 1/10W
R843 1-216-853-11 METAL CHIP 470K 5% 1/10W
R844 1-216-797-11 METAL CHIP 10 5% 1/10W
R845 1-216-801-11 METAL CHIP 22 5% 1/10W
R846 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R848 1-216-821-11 METAL CHIP 1K 5% 1/10W
R849 1-216-837-11 METAL CHIP 22K 5% 1/10W
R850 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R851 1-216-833-11 METAL CHIP 10K 5% 1/10W
R852 1-216-801-11 METAL CHIP 22 5% 1/10W
R853 1-216-845-11 METAL CHIP 100K 5% 1/10W
R859 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(AEP, RU, SP)
R859 1-216-833-11 METAL CHIP 10K 5% 1/10W
(E2, AR)
R860 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(AEP, RU, SP)
R860 1-216-833-11 METAL CHIP 10K 5% 1/10W
(E2, AR)
R862 1-216-801-11 METAL CHIP 22 5% 1/10W
R863 1-216-837-11 METAL CHIP 22K 5% 1/10W
R864 1-216-797-11 METAL CHIP 10 5% 1/10W
R865 1-216-801-11 METAL CHIP 22 5% 1/10W
R901 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R902 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R904 1-216-833-11 METAL CHIP 10K 5% 1/10W
R905 1-216-841-11 METAL CHIP 47K 5% 1/10W
R906 1-216-817-11 METAL CHIP 470 5% 1/10W
R907 1-216-837-11 METAL CHIP 22K 5% 1/10W
R908 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R909 1-216-833-11 METAL CHIP 10K 5% 1/10W
R922 1-216-793-11 METAL CHIP 4.7 5% 1/10W
R923 1-216-849-11 METAL CHIP 220K 5% 1/10W
R1021 1-216-805-11 METAL CHIP 47 5% 1/10W
R1022 1-216-805-11 METAL CHIP 47 5% 1/10W
R1023 1-216-805-11 METAL CHIP 47 5% 1/10W
R1024 1-216-805-11 METAL CHIP 47 5% 1/10W
R1025 1-216-805-11 METAL CHIP 47 5% 1/10W
R1026 1-216-805-11 METAL CHIP 47 5% 1/10W
R1027 1-216-805-11 METAL CHIP 47 5% 1/10W
R1028 1-216-805-11 METAL CHIP 47 5% 1/10W
R1029 1-216-805-11 METAL CHIP 47 5% 1/10W
R1030 1-216-805-11 METAL CHIP 47 5% 1/10W
R1031 1-216-805-11 METAL CHIP 47 5% 1/10W
R1032 1-216-805-11 METAL CHIP 47 5% 1/10W
R1041 1-216-805-11 METAL CHIP 47 5% 1/10W
R1042 1-216-805-11 METAL CHIP 47 5% 1/10W
R1043 1-216-805-11 METAL CHIP 47 5% 1/10W
R1044 1-216-805-11 METAL CHIP 47 5% 1/10W
R1045 1-216-805-11 METAL CHIP 47 5% 1/10W
R1046 1-216-805-11 METAL CHIP 47 5% 1/10W
R1047 1-216-805-11 METAL CHIP 47 5% 1/10W
R1048 1-216-805-11 METAL CHIP 47 5% 1/10W
R1049 1-216-805-11 METAL CHIP 47 5% 1/10W
R1050 1-216-805-11 METAL CHIP 47 5% 1/10W
R1051 1-216-805-11 METAL CHIP 47 5% 1/10W
R1052 1-216-805-11 METAL CHIP 47 5% 1/10W
< RELAY >
RY131 1-755-307-11 RELAY
< CABLE HOLDER >
WH001 1-819-972-11 HOLDER, CABLE 8P
< VIBRATOR >
X801 1-813-917-11 VIBRATOR, CRYSTAL (75kHz)
************************************************************
A-1221-544-A PANEL BOARD, COMPLETE (AEP)
(Refer to SUPPLEMENT-1 about Suffix-12, -13)
**********************
2-636-531-01 HOLDER (LCD)
2-636-532-01 ILLUMINATOR (LCD)
2-697-163-01 SHEET (LCD)
< CAPACITOR >
C602 1-126-964-11 ELECT 10uF 20% 50V
C603 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C611 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C701 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C702 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C703 1-104-658-91 ELECT 100uF 20% 10V
C704 1-126-925-91 ELECT 470uF 20% 10V
C705 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C706 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C707 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
Ver. 1.1
