– 9 –
3
Screw (+BVTP2.6X8)
4
CN291
(5 pin)
TCB Board
(TCB017)
6
Screw (+BVTT3X6)
Main Board
3
Screw (+BVTP2.6X8)
Mechanism Deck Section
(TCM-220WR2)
4
Screw (+BVTP2.6X8)
6
Screw (+BVTT3X6)
Button
(EJ-R)
Button
(EJ-L)
7
CD MECHANISM SECTION
(CDM28-5BD19)
2
Wire (Flat Type) (11 core)
1
Wire (Flat Type) (21 core)
3-2.
CD MECHANISM,
MAIN BO
ARD AND
TCB BO
ARD
3-3.
MECHANISM DECK REMO
V
AL
8
10
Table of Contents
Default Chapter
2
Table of Contents
2
1 Servicing Notes
3
2 General
4
3 Disassembly
8
Front Panel Removal
8
Mechanism Deck Removal
9
4 Adjustments
10
Mechanical Adjustment
10
Electrical Adjustment
10
5 Explanation of IC Terminals
16
7 Exploded Views
30
Front Panel Section
32
TC Mechanism Section-1
34
TC Mechanism Section-2
35
CD Mechanism Section-1
36
CD Mechanism Section-2
37
8 Electrical Parts List
38
