Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
151 3-908-560-01 SPRING, AZIMUTH ADJUSTMENT
152 3-919-684-01 SCREW, AZIMUTH ADJUSTMENT
153 X-3370-844-1 SLIDER (HEAD) ASSY
154 3-908-556-01 SPRING, HEAD TOGGLE
155 3-908-558-02 FITTING BLOCK, HEAD
156 3-908-557-02 ROTARY BLOCK, HEAD
* 157 3-908-559-01 STOPPER, AZIMUTH
158 3-908-555-01 SLIDER (REV SLIDER)
159 3-917-143-11 SPRING, TENSION
160 3-388-848-01 SCREW (P2X6) (B TIGHT)
161 3-911-113-01 SPRING, TENSION
162 X-3369-909-1 PINCH LEVER (REV) ASSY
163 X-3369-908-1 PINCH LEVER (FWD) ASSY
164 3-908-613-01 GEAR (S), REEL
165 3-917-141-01 SPRING, COMPRESSION
166 X-3371-305-1 REEL (T) ASSY
167 3-669-465-01 WASHER (1.5), STOPPER
168 X-3370-173-1 TU ASSY
* 169 4-980-439-01 FULCRUM, HOLDER
170 3-917-142-01 SPRING, COMPRESSION
171 3-911-116-21 RIVET, PUSH
* 172 A-2007-131-A AUDIO BOARD, COMPLETE
173 3-930-972-01 DETENT, HALF
174 3-354-963-01 DAMPER
175 3-911-116-11 RIVET, PUSH
HP101 1-500-093-11 HEAD, MAGNETIC (PLAYBACK) (DECK A)
HRPE1011-500-094-11 HEAD, MAGNETIC (REC/PB/ERASE) (DECK B)
(4) TAPE MECHANISM SECTION-1
