– 86 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R26 1-249-437-11 CARBON 47K 5% 1/4W
R27 1-249-429-11 CARBON 10K 5% 1/4W
R28 1-249-417-11 CARBON 1K 5% 1/4W
R29 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R30 1-216-186-00 METAL CHIP 330 5% 1/8W
R31 1-216-025-00 METAL CHIP 100 5% 1/10W
R32 1-249-425-11 CARBON 4.7K 5% 1/4W
R33 1-249-425-11 CARBON 4.7K 5% 1/4W
R34 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R35 1-216-214-00 METAL CHIP 4.7K 5% 1/8W
R36 1-216-025-00 METAL CHIP 100 5% 1/10W
R37 1-216-073-00 METAL CHIP 10K 5% 1/10W
R38 1-216-089-00 METAL CHIP 47K 5% 1/10W
R39 1-249-429-11 CARBON 10K 5% 1/4W
R42 1-216-073-00 METAL CHIP 10K 5% 1/10W
R43 1-216-042-00 METAL CHIP 510 5% 1/10W
R44 1-216-021-00 METAL CHIP 68 5% 1/10W
R45 1-247-843-11 CARBON 3.3K 5% 1/4W
R46 1-216-073-00 METAL CHIP 10K 5% 1/10W
R47 1-216-097-00 METAL CHIP 100K 5% 1/10W
R48 1-249-417-11 CARBON 1K 5% 1/4W
R49 1-216-049-00 METAL CHIP 1.0K 5% 1/10W
R50 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R51 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R53 1-249-429-11 CARBON 10K 5% 1/4W
R54 1-249-399-11 CARBON 33 5% 1/4W
(E3, EA, MY, SP, HK)
R55 1-216-162-00 METAL CHIP 33 5% 1/8W
R56 1-249-393-11 CARBON 10 5% 1/4W
R91 1-216-295-00 CONDUCTOR, CHIP (2012)(AEP, UK)
R91 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
(E3, EA, MY, SP, HK)
R92 1-216-073-00 METAL CHIP 10K 5% 1/10W
(AEP, UK, E3, EA, MY, SP, HK)
R93 1-216-073-00 METAL CHIP 0K 5% 1/10W
(E3, EA, MY, SP, HK)
R94 1-216-073-00 METAL CHIP 10K 5% 1/10W
(AEP, UK, E3, EA, MY, SP, HK)
< VARIABLE RESISTOR>
RV41 1-238-601-11 RES,ADJ,CARBON 22K
RV42 1-238-600-11 RES,ADJ,CARBON 10K
<COIL>
T1 1-409-505-11 COIL (ANT.SW3) (E3, EA, MY, SP, HK)
T2 1-402-960-11 COIL (OSC.SW3) (E3, EA, MY, SP, HK)
<TERMINAL>
TM1 1-537-238-21 TERMINAL BOARD(ANT) (ANTENNA)
(EXCEPT AEP, G, IT, UK)
TM1 1-537-488-11 TERMINAL BOARD(ANT) (ANTENNA)
(AEP, G, T, UK)
<VIBRATOR>
X21 1-760-549-11 VIBRATOR, CRYSTAL (4.5MHz)
X41 1-760-220-11 FILTER, CERAMIC (10.7MHz)
X42 1-527-981-00 FILTER, CERAMIC (450KHz)
X43 1-577-075-11 OSCILLATOR, CERAMIC (456KHz)
************************************************************
* 1-660-718-11 TRANS BOARD
************
1-533-217-31 HOLDER, FUSE
<CONNECTOR>
* CN851 1-580-230-31 PIN, CONNECTOR (PC BOARD) 2P
* CN852 1-564-525-11 PLUG, CONNECTOR 10P
<FUSE>
! F801 1-532-500-51 FUSE, CYLINDRICAL (TIME-LAG) (0.63A/250V)
! F802 1-532-502-51 FUSE (1.25A/250V)
(E2, E3, MY, SP, MX, EA, HK, AR)
<FUSIBLE RESISTOR>
! R814 1-219-119-81 FUSIBLE 0.1 5% 1/4W F
! R815 1-219-119-81 FUSIBLE 0.1 5% 1/4W F
<SWITCH>
! S801 1-572-675-11 SWITCH, POWER VOLTAGE CHANGE
(VOLTAGE SELECTOR)
(EXCEPT AEP, G, IT, UK, AUS)
<TRANSFORMER>
! T801 1-429-900-11 TRANSFORMER, POWER
(EXCEPT AEP, G, IT, UK)
! T801 1-429-901-11 TRANSFORMER, POWER (AEP, G, IT, UK)
************************************************************
TCB TRANS
The components identified by mark ! or
dotted line with mark ! are critical for
safety.
Replace only with part number specified.
