– 87 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
* A-4390-036-A WOOFER BOARD, COMPLETE (AEP, G, IT)
* A-4390-045-A WOOFER BOARD, COMPLETE (UK)
* A-4390-051-A WOOFER BOARD, COMPLETE
(E2, E3, EA, HK, AR, AUS)
* A-4390-058-A WOOFER BOARD, COMPLETE (MY, SP)
* A-4390-063-A WOOFER BOARD, COMPLETE (MX)
***********************
< CAPACITOR >
C1101 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C1102 1-163-007-11 CERAMIC CHIP 680PF 10% 50V
C1103 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C1105 1-126-964-11 ELECT 10uF 20% 50V
C1106 1-130-489-00 MYLAR 0.033uF 5% 50V
C1107 1-130-489-00 MYLAR 0.033uF 5% 50V
C1108 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C1109 1-126-964-11 ELECT 10uF 20% 50V
C1110 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C1151 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C1152 1-163-007-11 CERAMIC CHIP 680PF 10% 50V
C1153 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C1155 1-126-964-11 ELECT 10uF 20% 50V
C1156 1-130-489-00 MYLAR 0.033uF 5% 50V
C1157 1-130-489-00 MYLAR 0.033uF 5% 50V
C1158 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C1159 1-126-964-11 ELECT 10uF 20% 50V
C1160 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C2002 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C2004 1-126-964-11 ELECT 10uF 20% 50V
C2005 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C2007 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C2008 1-126-964-11 ELECT 10uF 20% 50V
C2009 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C2010 1-136-164-00 FILM 0.082uF 5% 50V
C2011 1-136-164-00 FILM 0.082uF 5% 50V
C2012 1-126-964-11 ELECT 10uF 20% 50V
C2013 1-136-167-00 FILM 0.15uF 5% 50V
C2014 1-136-167-00 FILM 0.15uF 5% 50V
C2021 1-124-903-11 ELECT 1uF 20% 50V
C2022 1-124-903-11 ELECT 1uF 20% 50V
<CONNECTOR>
CN201 1-774-292-11 HOUSING,CONNECTOR (PC BOARD)15P
<IC>
IC1001 8-759-636-55 IC M5218AFP
IC1002 8-759-100-96 IC uPC4558G2
IC2001 8-759-100-96 IC uPC4558G2
IC2002 8-759-100-96 IC uPC4558G2
<JUMPER RESISTOR>
JR157 1-216-295-00 CONDUCTOR, CHIP (2012)
JR159 1-216-295-00 CONDUCTOR, CHIP (2012)
JR162 1-216-295-00 CONDUCTOR, CHIP (2012)
JR163 1-216-296-00 CONDUCTOR, CHIP (3216)
JR164 1-216-296-00 CONDUCTOR, CHIP (3216)
JR165 1-216-295-00 CONDUCTOR, CHIP (2012)
JR166 1-216-295-00 CONDUCTOR, CHIP (2012)
JR167 1-216-295-00 CONDUCTOR, CHIP (2012)
JR168 1-216-296-00 CONDUCTOR, CHIP (3216)
JR169 1-216-295-00 CONDUCTOR, CHIP (2012)
JR171 1-216-295-00 CONDUCTOR, CHIP (2012)
JR173 1-216-296-00 CONDUCTOR, CHIP (3216)
JR174 1-216-296-00 CONDUCTOR, CHIP (3216)
<TRANSISTOR>
Q2002 8-729-421-22 TRANSISTOR UN2211
Q2003 8-729-421-22 TRANSISTOR UN2211
<RESISTOR>
R1101 1-216-113-00 METAL CHIP 470K 5% 1/10W
R1102 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R1103 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R1104 1-216-091-00 METAL CHIP 56K 5% 1/10W
R1105 1-216-073-00 METAL CHIP 10K 5% 1/10W
R1106 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R1107 1-216-049-00 METAL GLAZE 1K 5% 1/10W
R1108 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R1110 1-216-308-00 METAL CHIP 4.7 5% 1/10W
R1151 1-216-113-00 METAL CHIP 470K 5% 1/10W
R1152 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R1153 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R1154 1-216-091-00 METAL CHIP 56K 5% 1/10W
R1155 1-249-429-11 CARBON 10K 5% 1/4W
R1156 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R1157 1-216-049-00 METAL GLAZE 1K 5% 1/10W
R1158 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R1160 1-216-308-00 METAL CHIP 4.7 5% 1/10W
R2001 1-249-429-11 CARBON 10K 5% 1/4W
R2003 1-216-073-00 METAL CHIP 10K 5% 1/10W
R2004 1-216-071-00 METAL CHIP 8.2K 5% 1/10W
R2005 1-216-081-00 METAL CHIP 22K 5% 1/10W
R2006 1-216-081-00 METAL CHIP 22K 5% 1/10W
