– 88 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R2007 1-216-113-00 METAL CHIP 470K 5% 1/10W
R2008 1-216-073-00 METAL CHIP 10K 5% 1/10W
R2009 1-247-895-00 CARBON 470K 5% 1/4W
R2011 1-216-073-00 METAL CHIP 10K 5% 1/10W
R2012 1-216-091-00 METAL CHIP 56K 5% 1/10W
R2013 1-249-429-11 CARBON 10K 5% 1/4W
R2014 1-216-073-00 METAL CHIP 10K 5% 1/10W
R2015 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R2016 1-216-049-00 METAL GLAZE 1K 5% 1/10W
R2019 1-216-113-00 METAL CHIP 470K 5% 1/10W
R2020 1-216-113-00 METAL CHIP 470K 5% 1/10W
************************************************************
MISCELLANEOUS
**************
6 1-773-052-11 WIRE (FLAT TYPE) (17 CORE)
! 12 1-569-007-11 ADAPTOR, CONVERSION 2P (E3)
! 13 1-569-008-11 ADAPTOR, CONVERSION 2P (EA, MY, SP)
! 14 1-770-019-12 ADAPTOR, CONVERSION PLUG 3P (HK)
59 1-777-060-11 WIRE (FLAT TYPE) (21 CORE)
60 1-777-062-11 WIRE (FLAT TYPE) (11 CORE)
252 1-452-719-11 MAGNET ASSY
262 1-776-220-11 WIRE (FLAT TYPE) (19 CORE)
! 304 8-848-387-01 OPTICAL PICK-UP KSS-213BA/S-N
305 1-769-069-11 WIRE (FLAT TYPE) (16 CORE)
! CNP801 1-558-943-41 CORD, POWER (E, MX)
! CNP801 1-575-651-21 CORD, POWER (AEP, G, IT, EA, MY, SP, HK, AR)
! CNP801 1-696-845-11 CORD, POWER (AUS)
! CNP801 1-751-522-11 CORD, POWER (UK)
HP101 1-500-093-11 HEAD, MAGNETIC (PLAYBACK) (DECK A)
HRPE1011-500-094-11 HEAD, MAGNETIC (REC/PB/ERASE) (DECK B)
M1 X-3371-223-1 MOTOR ASSY, CAPSTAN
M2 A-2004-410-A MOTOR ASSY, DC (TRIGGER)
M101 X-4917-504-1 MOTOR ASSY (SLED)
M102 X-4917-523-4 MOTOR ASSY (SPINDLE)
M903 A-4604-363-A MOTOR (L) ASSY (LOADING)
Q805 8-729-141-83 TRANSISTOR 2SB1375
! T801 1-429-900-11 TRANSFORMER, POWER (EXCEPT AEP, G, IT, UK)
! T801 1-429-901-11 TRANSFORMER, POWER (AEP, G, IT, UK)
************************************************************
******************
HARDWARE LIST
******************
#1 7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
#2 7-685-662-79 SCREW +BVTP 4X14 TYPE2 N-S
#3 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#4 7-685-533-19 SCREW +BTP 2.6X6 TYPE2 N-S
#5 7-685-862-09 SCREW +BVTT 2.6X6 (S)
#6 7-685-131-19 SCREW +BTP 2.6X4 TYPE2 N-S
#7 7-621-775-10 SCREW +B 2.6X4
#8 7-623-921-01 RING, RETAINING, CAPSTAN
#9 7-621-775-00 SCREW +B 2.6X3
#10 7-685-534-19 SCREW +BTP 2.6X8 TYPE2 N-S
#11 7-621-255-15 SCREW +P 2X3
WOOFER
HCD-H33D
Sony Corporation
Home A&V Products Company
English
96H0576-1
Printed in Japan
© 1996. 8
Published by Quality Engineering Dept.
(Shibaura)
9-960-743-11
The components identified by mark ! or
dotted line with mark ! are critical for
safety.
Replace only with part number specified.
