Sony HCD-MC1 - Electrical Parts List; BD, CD Door, CD LED, CD Motor, Disc Sensor Parts List

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 91 —
< RESISTOR >
R101 1-216-097-91 RES,CHIP 100K 5% 1/10W
R102 1-216-093-00 METAL CHIP 68K 5% 1/10W
R103 1-216-093-00 METAL CHIP 68K 5% 1/10W
R104 1-216-093-00 METAL CHIP 68K 5% 1/10W
R105 1-216-093-00 METAL CHIP 68K 5% 1/10W
R106 1-216-097-91 RES,CHIP 100K 5% 1/10W
R107 1-216-097-91 RES,CHIP 100K 5% 1/10W
R108 1-216-068-00 METAL CHIP 6.2K 5% 1/10W
R109 1-216-076-00 METAL CHIP 13K 5% 1/10W
R110 1-216-093-00 METAL CHIP 68K 5% 1/10W
R111 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R112 1-216-101-00 METAL CHIP 150K 5% 1/10W
R113 1-216-099-00 METAL CHIP 120K 5% 1/10W
R114 1-216-055-00 METAL CHIP 1.8K 5% 1/10W
R115 1-216-085-00 METAL CHIP 33K 5% 1/10W
R116 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R117 1-216-085-00 METAL CHIP 33K 5% 1/10W
R118 1-216-081-00 METAL CHIP 22K 5% 1/10W
R119 1-216-064-00 METAL CHIP 4.3K 5% 1/10W
R120 1-216-085-00 METAL CHIP 33K 5% 1/10W
R121 1-216-059-00 METAL CHIP 2.7K 5% 1/10W
R122 1-216-083-00 METAL CHIP 27K 5% 1/10W
R123 1-216-099-00 METAL CHIP 120K 5% 1/10W
R124 1-216-093-00 METAL CHIP 68K 5% 1/10W
R125 1-216-089-91 RES,CHIP 47K 5% 1/10W
R126 1-216-037-00 METAL CHIP 330 5% 1/10W
R127 1-216-089-91 RES,CHIP 47K 5% 1/10W
R128 1-216-077-00 METAL CHIP 15K 5% 1/10W
R129 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R130 1-216-113-00 METAL CHIP 470K 5% 1/10W
R131 1-216-113-00 METAL CHIP 470K 5% 1/10W
R132 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R133 1-216-113-00 METAL CHIP 470K 5% 1/10W
R134 1-216-113-00 METAL CHIP 470K 5% 1/10W
R135 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R136 1-216-073-00 METAL CHIP 10K 5% 1/10W
R137 1-216-009-00 METAL CHIP 22 5% 1/10W
R138 1-216-089-91 RES,CHIP 47K 5% 1/10W
R141 1-216-083-00 METAL CHIP 27K 5% 1/10W
R151 1-216-045-00 METAL CHIP 680 5% 1/10W
R152 1-216-093-00 METAL CHIP 68K 5% 1/10W
R153 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
R154 1-216-085-00 METAL CHIP 33K 5% 1/10W
R155 1-216-089-91 RES,CHIP 47K 5% 1/10W
R156 1-216-081-00 METAL CHIP 22K 5% 1/10W
R157 1-216-077-00 METAL CHIP 15K 5% 1/10W
R158 1-216-049-91 RES,CHIP 1K 5% 1/10W
R159 1-216-083-00 METAL CHIP 27K 5% 1/10W
R160 1-216-037-00 METAL CHIP 330 5% 1/10W
R161 1-216-073-00 METAL CHIP 10K 5% 1/10W
R162 1-216-037-00 METAL CHIP 330 5% 1/10W
R163 1-216-049-91 RES,CHIP 1K 5% 1/10W
R164 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R165 1-216-025-91 RES,CHIP 100 5% 1/10W
R166 1-216-025-91 RES,CHIP 100 5% 1/10W
R171 1-216-025-91 RES,CHIP 100 5% 1/10W
R172 1-216-025-91 RES,CHIP 100 5% 1/10W
R173 1-216-025-91 RES,CHIP 100 5% 1/10W
R174 1-216-025-91 RES,CHIP 100 5% 1/10W
R181 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R182 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R183 1-216-073-00 METAL CHIP 10K 5% 1/10W
R184 1-216-073-00 METAL CHIP 10K 5% 1/10W
R191 1-216-025-91 RES,CHIP 100 5% 1/10W
R192 1-216-041-00 METAL CHIP 470 5% 1/10W
R193 1-216-041-00 METAL CHIP 470 5% 1/10W
R194 1-216-025-91 RES,CHIP 100 5% 1/10W
R195 1-216-041-00 METAL CHIP 470 5% 1/10W
R196 1-216-025-91 RES,CHIP 100 5% 1/10W
R197 1-216-025-91 RES,CHIP 100 5% 1/10W
< SWITCH >
S101 1-572-085-11 SWITCH, LEAF (LIMIT SW)
< VIBRATOR >
X101 1-577-576-21 VIBRATOR, CRYSTAL 16.93MHz
************************************************************
* 1-669-650-11 CD DOOR BOARD
**************
< SWITCH >
S413 1-762-386-11 SWITCH, PUSH (CD DOOR)
************************************************************
* 1-669-645-11 CD LED BOARD
*************
< DIODE >
D637 8-719-058-64 DIODE SEL5823A
D638 8-719-058-64 DIODE SEL5823A
D639 8-719-058-03 DIODE SEL5423E
D640 8-719-058-04 DIODE SEL5223S
< RESISTOR >
R653 1-249-402-11 CARBON 56 5% 1/4W F
R654 1-249-402-11 CARBON 56 5% 1/4W F
************************************************************
* 1-663-974-11 CD MOTOR BOARD
***************
< CONNECTOR >
CN61 1-506-469-11 PIN, CONNECTOR 4P
M61 X-4948-434-1 MOTOR ASSY (LOADING)
M62 X-4948-434-1 MOTOR ASSY (TABLE)
************************************************************
* 1-663-972-11 DISC SENSOR (R) BOARD
*********************
* 4-990-669-01 HOLDER (SENSOR)
7-685-132-19 SCREW +BTP 2.6X5 TYPE2 N-S
< TRANSISTOR >
Q51 8-729-926-31 PHOTO TRANSISTOR PT483F1S
************************************************************
BD
CD DOOR CD LED DISC SENSOR (R)CD MOTOR
