Sony HCD-MC1 - Electrical Parts List; Main Board Parts List

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 94 —
C917 1-126-768-11 ELECT 2200uF 20% 16V
C918 1-126-968-11 ELECT 100uF 20% 50V
C919 1-126-968-11 ELECT 100uF 20% 50V
C921 1-126-947-11 ELECT 47uF 20% 35V
C922 1-164-159-21 CERAMIC 0.1uF 50V
C923 1-164-159-21 CERAMIC 0.1uF 50V
C924 1-126-934-11 ELECT 220uF 20% 10V
C951 1-136-165-00 FILM 0.1uF 5% 50V
C952 1-126-943-11 ELECT 2200uF 20% 25V
C953 1-104-666-11 ELECT 220uF 20% 25V
C955 1-126-940-11 ELECT 330uF 20% 16V
< CONNECTOR >
* CN101 1-564-506-11 PLUG, CONNECTOR 3P
* CN102 1-568-832-11 SOCKET, CONNECTOR 13P
CN106 1-784-776-41 CONNECTOR, FFC 15P
CN107 1-784-778-41 CONNECTOR, FFC 17P
* CN108 1-568-954-11 PIN, CONNECTOR 5P
* CN110 1-564-506-11 PLUG, CONNECTOR 3P
* CN301 1-568-449-11 HO(US)ING, CONNECTOR(PC BOARD)3P
CN401 1-784-738-41 CONNECTOR, FFC 16P
CN402 1-784-731-41 CONNECTOR, FFC 9P
* CN403 1-568-951-11 PIN, CONNECTOR 2P
* CN451 1-568-955-11 PIN, CONNECTOR 6P
* CN453 1-568-951-11 PIN, CONNECTOR 2P
CN454 1-506-468-11 PIN, CONNECTOR 3P
CN461 1-506-469-11 PIN, CONNECTOR 4P
CN501 1-784-770-41 CONNECTOR, FFC 9P
CN607 1-506-481-11 PIN, CONNECTOR 2P
< DIODE >
D141 8-719-991-33 DIODE 1SS133T-77
D333 8-719-991-33 DIODE 1SS133T-77
D401 8-719-024-99 DIODE 11ES2-NTA2B
D402 8-719-991-33 DIODE 1SS133T-77
D411 8-719-991-33 DIODE 1SS133T-77
D501 8-719-024-99 DIODE 11ES2-NTA2B
D502 8-719-024-99 DIODE 11ES2-NTA2B
D503 8-719-991-33 DIODE 1SS133T-77
D504 8-719-991-33 DIODE 1SS133T-77
D505 8-719-991-33 DIODE 1SS133T-77
D506 8-719-991-33 DIODE 1SS133T-77
D701 8-719-991-33 DIODE 1SS133T-77
D702 8-719-991-33 DIODE 1SS133T-77
D703 8-719-024-99 DIODE 11ES2-NTA2B
D704 8-719-024-99 DIODE 11ES2-NTA2B
D705 8-719-024-99 DIODE 11ES2-NTA2B
D731 8-719-991-33 DIODE 1SS133T-77
D732 8-719-991-33 DIODE 1SS133T-77
D733 8-719-991-33 DIODE 1SS133T-77
D751 8-719-991-33 DIODE 1SS133T-77
D901 8-719-024-99 DIODE 11ES2-NTA2B
D902 8-719-024-99 DIODE 11ES2-NTA2B
D903 8-719-024-99 DIODE 11ES2-NTA2B
D904 8-719-024-99 DIODE 11ES2-NTA2B
D905 8-719-933-36 DIODE HZS6B1LTA
C405 1-162-306-11 CERAMIC 0.01uF 30% 16V
C406 1-104-665-11 ELECT 100uF 20% 10V
C410 1-104-665-11 ELECT 100uF 20% 10V
C411 1-110-489-11 CAPACITOR 1F 5.5V
C412 1-164-159-21 CERAMIC 0.1uF 50V
C413 1-162-294-31 CERAMIC 0.001uF 10% 50V
C442 1-124-252-00 ELECT 0.33uF 20% 50V
C443 1-130-477-00 MYLAR 0.0033uF 5% 50V
C444 1-130-477-00 MYLAR 0.0033uF 5% 50V
C451 1-126-934-11 ELECT 220uF 20% 10V
C453 1-164-159-21 CERAMIC 0.1uF 50V
C455 1-164-159-11 CERAMIC 0.1uF 50V
C456 1-164-159-21 CERAMIC 0.1uF 50V
C457 1-164-159-21 CERAMIC 0.1uF 50V
C458 1-164-159-21 CERAMIC 0.1uF 50V
C460 1-164-159-21 CERAMIC 0.1uF 50V
C461 1-126-964-11 ELECT 10uF 20% 50V
C462 1-162-294-31 CERAMIC 0.001uF 10% 50V
C463 1-162-294-31 CERAMIC 0.001uF 10% 50V
C492 1-124-252-00 ELECT 0.33uF 20% 50V
C493 1-130-477-00 MYLAR 0.0033uF 5% 50V
C494 1-130-477-00 MYLAR 0.0033uF 5% 50V
C499 1-161-494-00 CERAMIC 0.022uF 25V
C501 1-104-664-11 ELECT 47uF 20% 10V
C502 1-164-159-21 CERAMIC 0.1uF 50V
C503 1-136-173-00 FILM 0.47uF 5% 50V
C504 1-126-926-11 ELECT 1000uF 20% 10V
C505 1-162-306-11 CERAMIC 0.01uF 30% 16V
C506 1-136-165-00 FILM 0.1uF 5% 50V
C507 1-164-159-21 CERAMIC 0.1uF 50V
C508 1-104-665-11 ELECT 100uF 20% 10V
C509 1-164-027-11 CERAMIC 22PF 5% 50V
C510 1-164-027-11 CERAMIC 22PF 5% 50V
C512 1-164-159-11 CERAMIC 0.1uF 50V
C513 1-136-165-00 FILM 0.1uF 5% 50V
C571 1-109-889-11 ELECT 1uF 20% 50V
C701 1-136-495-11 FILM 0.068uF 5% 50V
C702 1-136-495-11 FILM 0.068uF 5% 50V
C731 1-126-934-11 ELECT 220uF 20% 10V
C732 1-104-665-11 ELECT 100uF 20% 10V
C733 1-126-960-11 ELECT 1uF 20% 50V
C734 1-104-665-11 ELECT 100uF 20% 10V
C751 1-136-495-11 FILM 0.068uF 5% 50V
C752 1-136-495-11 FILM 0.068uF 5% 50V
C756 1-126-963-11 ELECT 4.7uF 20% 50V
C757 1-164-159-21 CERAMIC 0.1uF 50V
C901 1-136-165-00 FILM 0.1uF 5% 50V
C902 1-128-548-11 ELECT 4700uF 20% 25V
C903 1-104-666-11 ELECT 220uF 20% 25V
C904 1-104-664-11 ELECT 47uF 20% 16V
C905 1-126-940-11 ELECT 330uF 20% 16V
C908 1-162-301-11 CERAMIC 0.0015uF 30% 16V
C909 1-126-964-11 ELECT 10uF 20% 50V
C910 1-104-665-11 ELECT 100uF 20% 10V
C911 1-126-964-11 ELECT 10uF 20% 50V
C912 1-126-926-11 ELECT 1000uF 20% 10V
C913 1-126-943-11 ELECT 2200uF 20% 25V
C914 1-126-964-11 ELECT 10uF 20% 50V
C915 1-126-767-11 ELECT 1000uF 20% 16V
C916 1-126-964-11 ELECT 10uF 20% 50V
MAIN
