Sony HCD-MC1 - Electrical Parts List; Panel, Power Amp, SW;Power, Table Sensor, Trans Parts List

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 99 —
S616 1-762-875-21 SWITCH, KEYBOARD(),+)
S617 1-762-875-21 SWITCH, KEYBOARD(TAPE B 9)
S618 1-762-875-21 SWITCH, KEYBOARD(TAPE B ()
S619 1-762-875-21 SWITCH, KEYBOARD(CD/PLAY)
S620 1-762-875-21 SWITCH, KEYBOARD(GROOVE)
S621 1-762-875-21 SWITCH, KEYBOARD(DBFB)
S622 1-762-875-21 SWITCH, KEYBOARD(SUR)
S623 1-762-875-21 SWITCH, KEYBOARD(STOP)
S651 1-473-392-31 ENCODER, ROTARY(VOLUME)
S652 1-473-534-11 ENCODER, ROTARY(SELECTOR)
< VIBRATOR >
X601 1-579-952-21 VIBRATOR, CERAMIC(8MHz)
************************************************************
A-4426-598-A POWER AMP BOARD, COMPLETE (US)
***************************
A-4426-599-A POWER AMP BOARD, COMPLETE (E)
***************************
< CAPACITOR >
C801 1-128-582-11 ELECT 10uF 20% 100V
C802 1-163-007-11 CERAMIC CHIP 680PF 10% 50V
C803 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C804 1-126-967-11 ELECT 47uF 20% 50V
C806 1-126-967-11 ELECT 47uF 20% 50V
C807 1-128-560-11 ELECT 22uF 20% 100V
C809 1-128-560-11 ELECT 22uF 20% 100V
C810 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C811 1-136-163-00 FILM 0.068uF 5% 50V
C812 1-136-163-00 FILM 0.068uF 5% 50V
C821 1-106-220-00 MYLAR 0.1uF 5% 100V
C822 1-117-750-11 ELECT 3300uF 20% 63V
C823 1-126-925-11 ELECT 470uF 20% 10V
C851 1-128-582-11 ELECT 10uF 20% 100V
C852 1-163-007-11 CERAMIC CHIP 680PF 10% 50V
C853 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C854 1-126-967-11 ELECT 47uF 20% 50V
C856 1-126-967-11 ELECT 47uF 20% 50V
C857 1-128-560-11 ELECT 22uF 20% 100V
C861 1-136-163-00 FILM 0.068uF 5% 50V
C862 1-136-163-00 FILM 0.068uF 5% 50V
C871 1-106-220-00 MYLAR 0.1uF 5% 100V
C872 1-117-750-11 ELECT 3300uF 20% 63V
< CONNECTOR >
* CN803 1-564-511-11 PLUG, CONNECTOR 8P
< DIODE >
D801 8-719-988-61 DIODE 1SS355TE-17
D811 8-719-988-61 DIODE 1SS355TE-17
D812 8-719-988-61 DIODE 1SS355TE-17
D813 8-719-988-61 DIODE 1SS355TE-17
D821 8-719-510-68 DIODE D5SBA204101
D851 8-719-988-61 DIODE 1SS355TE-17
< IC >
IC801 8-749-922-65 IC STK4221MK2 (US)
IC801 8-749-921-68 IC STK4231MK2 (E)
R625 1-216-089-91 RES,CHIP 47K 5% 1/10W
R626 1-216-033-00 METAL CHIP 220 5% 1/10W
R627 1-216-089-91 RES,CHIP 47K 5% 1/10W
R628 1-216-033-00 METAL CHIP 220 5% 1/10W
R629 1-216-099-00 METAL CHIP 120K 5% 1/10W
R633 1-216-027-00 METAL CHIP 120 5% 1/10W
R634 1-216-027-00 METAL CHIP 120 5% 1/10W
R635 1-216-027-00 METAL CHIP 120 5% 1/10W
R636 1-216-027-00 METAL CHIP 120 5% 1/10W
R637 1-216-025-91 RES,CHIP 100 5% 1/10W
R637 1-216-028-00 METAL CHIP 130 5% 1/10W
R638 1-216-029-00 METAL CHIP 150 5% 1/10W
R645 1-216-033-00 METAL CHIP 220 5% 1/10W
R646 1-216-033-00 METAL CHIP 220 5% 1/10W
R648 1-216-033-00 METAL CHIP 220 5% 1/10W
R649 1-216-033-00 METAL CHIP 220 5% 1/10W
R650 1-216-033-00 METAL CHIP 220 5% 1/10W
R651 1-216-033-00 METAL CHIP 220 5% 1/10W
R655 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R661 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R662 1-216-033-00 METAL CHIP 220 5% 1/10W
R663 1-216-035-00 METAL CHIP 270 5% 1/10W
R664 1-216-039-00 METAL CHIP 390 5% 1/10W
R665 1-216-041-00 METAL CHIP 470 5% 1/10W
R666 1-216-045-00 METAL CHIP 680 5% 1/10W
R667 1-216-047-91 RES,CHIP 820 5% 1/10W
R668 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
R669 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R670 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R671 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R672 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R673 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R674 1-216-073-00 METAL CHIP 10K 5% 1/10W
R675 1-216-079-00 METAL CHIP 18K 5% 1/10W
R676 1-216-689-11 METAL CHIP 39K 0.5% 1/10W
R677 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R678 1-216-033-00 METAL CHIP 220 5% 1/10W
R679 1-216-035-00 METAL CHIP 270 5% 1/10W
R680 1-216-039-00 METAL CHIP 390 5% 1/10W
R681 1-216-041-00 METAL CHIP 470 5% 1/10W
R682 1-216-045-00 METAL CHIP 680 5% 1/10W
R683 1-216-047-91 RES,CHIP 820 5% 1/10W
R685 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
< SWITCH >
S601 1-762-875-21 SWITCH, KEYBOARD(TAPE A ()
S602 1-762-875-21 SWITCH, KEYBOARD(TAPE A 9)
S603 1-762-875-21 SWITCH, KEYBOARD(TUNER/BAND)
S604 1-762-875-21 SWITCH, KEYBOARD(DISPLAY/MEMO)
S605 1-762-875-21 SWITCH, KEYBOARD(CLOCK/TIMWER SET)
S606 1-762-875-21 SWITCH, KEYBOARD(DISPLAY/MEMORY)
S607 1-762-875-21 SWITCH, KEYBOARD(SEARCH)
S608 1-762-875-21 SWITCH, KEYBOARD(SCAN)
S609 1-762-875-21 SWITCH, KEYBOARD(INPUT)
S610 1-762-875-21 SWITCH, KEYBOARD(CHECK)
S611 1-762-875-21 SWITCH, KEYBOARD(CLEAR)
S612 1-762-875-21 SWITCH, KEYBOARD(DELETE)
S613 1-762-875-21 SWITCH, KEYBOARD(0,=)
S614 1-762-875-21 SWITCH, KEYBOARD(FILE SELECT)
S615 1-762-875-21 SWITCH, KEYBOARD(ENTER)
PANEL POWER AMP
