Sony HCD-MC1 - Miscellaneous Parts List; Hardware List

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 101 —
***************
MISCELLANEOUS
***************
5 1-693-457-11 ENCAPSULATED COMPONENT(TUNER UNIT)
6 1-769-972-11 WIRE(FLAT TYPE)(13 CORE)
6 1-773-004-11 WIRE(FLAT TYPE)(15 CORE)
8 1-765-332-11 WIRE (FLAT TYPE) (15 CORE)
9 1-773-055-11 WIRE (FLAT TYPE) (17 CORE)
95 1-769-920-11 WIRE (FLAT TYPE) (9 CORE)
! 109 1-569-007-21 ADAPTOR, CONVERSION 2P (E)
110 1-782-558-21 WIRE (FLAT TYPE) (16 CORE)
111 1-782-559-21 WIRE (FLAT TYPE) (9 CORE)
! 114 1-783-531-11 CORD, POWER (US)
! 114 1-575-653-11 CORD, POWER (E)
322 1-777-874-11 WIRE (FLAT TYPE) (16 CORE)
! 401 8-848-379-31 OPTICAL PICK-UP KSS-213BA/F-NP
FAN101 1-698-792-11 FAN, DC
HP101 A-2056-681-B DECK (A) ASSY, HEAD(230AWR2)(*NOTE)
HP101 A-2056-683-B DECK (A) ASSY, HEAD(230PWR2)(*NOTE)
HRPE101A-2056-682-B DECK (B) ASSY, HEAD(230AWR2)(*NOTE)
HRPE101A-2056-684-B DECK (B) ASSY, HEAD(230PWR2)(*NOTE)
M1 A-2004-628-A MOTOR ASSY, CAPSTAN
M101 X-2646-110-1 T, T CHASSIS ASSY (MG) (F) (SPINDLE)
M102 X-2625-769-1 MOTOR GEAR ASSY (MB) (RP) (SLED)
! T991 1-431-842-11 TRANSFORMER, POWER (E)
! T991 1-431-348-31 TRANSFORMER, POWER (US)
************************************************************
***************
HARDWARE LIST
***************
#1 7-685-646-79 SCREW +BVTP 3 × 8 TYPE2 N-S
#2 7-685-872-09 SCREW +BVTT 3 × 8 (S)
#3 7-685-871-01 SCREW +BVTT 3 × 6 (S)
#4 7-685-650-79 SCREW +BVTP 3 × 16 TYPE2 IT-3
#5 7-685-873-09 SCREW +BVTT 3 × 10 (S)
#6 7-685-875-09 SCREW +BVTT 3 × 14 (S)
#7 7-685-781-09 SCREW +PTT 2 × 4 (S)
#8 7-685-783-09 SCREW +PTT 2 × 6 (S)
#9 7-685-851-04 SCREW +BVTT 2 × 4 (S)
#10 7-685-534-19 SCREW +BTP 2.6 × 8 TYPE2 N-S
#11 7-628-254-15 SCREW +PS 2.6 × 6
#12 7-628-254-50 SCREW +PS 2.6 × 16
#13 7-685-850-04 SCREW +BVTT 2 × 3 (S)
#14 7-685-132-19 SCREW +BTP 2.6 × 5 TYPE2 N-S
#15 7-685-107-11 SCREW +P 2 × 12 TYPE2 NON-SLIT
#16 7-685-535-19 SCREW +BTP 2.6 × 10 TYPE2 N-S
#17 7-685-134-19 SCREW (+ PTPWH) (2.6 × 8)
#18 7-1685-103-19 + PTPWH (2 × 5)
#19 7-627-553-17 SCREW,PRECISION +P 2 × 2
#20 7-621-770-67 SCREW +PWH 2.6 × 6
#21 7-685-852-04 SCREW +BVTT 2 × 5 (S)
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
