HCD-PZ1D
7
LCD CTRL BOARD SERVICE POSITION
AMP BOARD SERVICE POSITION
Note: Set up the unit to lay it down sideway.
– Rear view –
LCD CTRL board
MAIN board
AMP board
TRANSFORMER board
TRANS-SUB board
sheet
front panel
