Sony HCD-PZ1D - Page 79

HCD-PZ1D
79
Pin No. Pin Name I/O Description
67 VSS18_3 — Ground
68 SPI_CSN O SPI CS (low enable) signal output (Not used in this set)
69 SPI_SDO O SPI data out signal output (Not used in this set)
70 SPI_SDI I SPI data in signal input (Connect to VSS18)
71 SPI_CLK O SPI clock out signal output (Not used in this set)
72 AVD3 — Power supply pin (+3.3 V)
73 ROUT O DAC analog red data output
74 GOUT O DAC analog green data output
75 BOUT O DAC analog blue data output
76, 77 SENSE0, SENSE1 I Analog sensing 0, 1 signal input
78, 79 ADCIN1, ADCIN0 I Low speed ADC input 1, 0 (Not used in this set)
80 AVS3 — Ground
