72
HCD-RV22/RV55
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< SWITCH >
S101 1-771-853-11 SWITCH, DETECTION (LIMIT)
*************************************************************
1-687-135-12 DRIVER BOARD
*************
< CAPACITOR >
C715 1-126-933-11 ELECT 100uF 20% 16V
C731 1-126-964-11 ELECT 10uF 20% 50V
C735 1-164-159-11 CERAMIC 0.1uF 50V
C736 1-164-159-11 CERAMIC 0.1uF 50V
C737 1-164-159-11 CERAMIC 0.1uF 50V
C741 1-162-306-11 CERAMIC 0.01uF 20% 16V
C751 1-162-306-11 CERAMIC 0.01uF 20% 16V
C752 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CN701 1-785-338-11 PIN, CONNECTOR (LIGHT ANGLE) 12P
CN702 1-784-766-11 CONNECTOR, FFC 5P
* CN703 1-564-720-11 PIN, CONNECTOR (SMALL TYPE) 4P
CN704 1-785-328-11 PIN, CONNECTOR (LIGHT ANGLE) 2P
< DIODE >
D701 8-719-947-16 DIODE MTZJ-T-72-5.1A
D711 8-719-983-66 DIODE MTZJ-T-72-3.6B
< IC >
IC701 8-759-598-69 IC BA6956AN
IC712 8-759-598-69 IC BA6956AN
< TRANSISTOR >
Q731 8-729-029-66 TRANSISTOR DTC114ESA
< RESISTOR >
R701 1-249-413-11 CARBON 470 5% 1/4W
R702 1-247-807-31 CARBON 100 5% 1/4W
R711 1-249-417-11 CARBON 1K 5% 1/4W
R712 1-249-425-11 CARBON 4.7K 5% 1/4W
R713 1-249-433-11 CARBON 22K 5% 1/4W
R721 1-249-425-11 CARBON 4.7K 5% 1/4W
R722 1-249-425-11 CARBON 4.7K 5% 1/4W
R723 1-249-425-11 CARBON 4.7K 5% 1/4W
R731 1-247-807-31 CARBON 100 5% 1/4W
R732 1-249-429-11 CARBON 10K 5% 1/4W
R733 1-249-417-11 CARBON 1K 5% 1/4W
R734 1-249-430-11 CARBON 12K 5% 1/4W
R735 1-247-807-31 CARBON 100 5% 1/4W
R751 1-249-425-11 CARBON 4.7K 5% 1/4W
*************************************************************
H/P JACK BOARD
**************
< CAPACITOR >
C830 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C831 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C832 1-164-156-11 CERAMIC CHIP 0.1uF 25V
< JACK >
J801 1-785-448-21 JACK (PHONES)
*************************************************************
A-4752-296-A MAIN BOARD, COMPLETE (RV55)
A-4752-356-A MAIN BOARD, COMPLETE (RV22)
*********************
7-685-872-09 SCREW +BVTT 3X8 (S)
< CAPACITOR >
C101 1-126-960-11 ELECT 1uF 20% 50V
C102 1-126-960-11 ELECT 1uF 20% 50V
C103 1-126-956-91 ELECT 0.1uF 20% 50V
C104 1-126-956-91 ELECT 0.1uF 20% 50V
C105 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C106 1-131-679-31 FILM 0.01uF 5% 50V
C107 1-126-964-11 ELECT 10uF 20% 50V
C108 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C109 1-131-679-31 FILM 0.01uF 5% 50V
C110 1-126-964-11 ELECT 10uF 20% 50V
C111 1-126-960-11 ELECT 1uF 20% 50V
C112 1-126-960-11 ELECT 1uF 20% 50V
C113 1-126-960-11 ELECT 1uF 20% 50V
C114 1-126-960-11 ELECT 1uF 20% 50V
C115 1-131-679-31 FILM 0.01uF 5% 50V
C116 1-164-392-11 CERAMIC CHIP 390PF 5% 50V
(RV55)
C116 1-164-816-11 CERAMIC CHIP 220PF 2% 50V
(RV22)
C117 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C118 1-126-964-11 ELECT 10uF 20% 50V
C119 1-131-679-31 FILM 0.01uF 5% 50V
C120 1-164-392-11 CERAMIC CHIP 390PF 5% 50V
(RV55)
C120 1-164-816-11 CERAMIC CHIP 220PF 2% 50V
(RV22)
C121 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C122 1-126-964-11 ELECT 10uF 20% 50V
C123 1-126-965-91 ELECT 22uF 20% 50V
C124 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C125 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C126 1-165-112-11 CERAMIC CHIP 0.33uF 16V
C127 1-104-658-91 ELECT 100uF 20% 10V
C128 1-104-658-91 ELECT 100uF 20% 10V
C129 1-126-947-11 ELECT 47uF 20% 35V
C132 1-126-947-11 ELECT 47uF 20% 35V
C135 1-131-690-31 FILM 0.068uF 5% 50V
C136 1-131-690-31 FILM 0.068uF 5% 50V
C137 1-126-964-11 ELECT 10uF 20% 50V
C138 1-126-964-11 ELECT 10uF 20% 50V
MAINBD49 DRIVER H/P JACK
