77
HCD-RV22/RV55
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C820 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C821 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C822 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C823 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C824 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C825 1-164-816-11 CERAMIC CHIP 220PF 2% 50V
C826 1-165-112-11 CERAMIC CHIP 0.33uF 16V
C827 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C828 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C829 1-126-157-11 ELECT 10uF 20% 16V
C830 1-126-157-11 ELECT 10uF 20% 16V
C831 1-165-112-11 CERAMIC CHIP 0.33uF 16V
C833 1-165-112-11 CERAMIC CHIP 0.33uF 16V
C834 1-162-951-11 CERAMIC CHIP 68PF 5% 50V
C835 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C836 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C837 1-126-157-11 ELECT 10uF 20% 16V
C838 1-119-941-91 ELECT 470uF 20% 6.3V
C839 1-124-589-11 ELECT 47uF 20% 16V
C841 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C842 1-162-969-11 CERAMIC CHIP 0.0068uF 10% 25V
C843 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C844 1-131-690-31 FILM 0.068uF 5% 50V
C845 1-124-589-11 ELECT 47uF 20% 16V
C846 1-124-589-11 ELECT 47uF 20% 16V
C847 1-126-160-11 ELECT 1uF 20% 50V
C848 1-136-167-00 FILM 0.15uF 5% 50V
C849 1-124-465-00 ELECT 0.47uF 20% 50V
C850 1-124-465-00 ELECT 0.47uF 20% 50V
C851 1-162-969-11 CERAMIC CHIP 0.0068uF 10% 25V
C852 1-131-690-31 FILM 0.068uF 5% 50V
C853 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C854 1-126-160-11 ELECT 1uF 20% 50V
C857 1-124-257-00 ELECT 2.2uF 20% 50V
C858 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C859 1-126-157-11 ELECT 10uF 20% 16V
C862 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
< DIODE >
D801 8-719-988-61 DIODE 1SS355TE-17
D802 8-719-988-61 DIODE 1SS355TE-17
D803 8-719-069-54 DIODE UDZSTE-175.1B
< IC >
IC801 8-759-710-97 IC NJM4565M-D
IC802 8-759-496-40 IC M65850FP
IC803 8-759-295-90 IC NJM2244M-TE2
< JACK >
J805 1-764-592-11 JACK, PIN 3P (MIC INPUT)
JK802 1-770-226-11 JACK (LARGE TYPE) (MIC)
< JUMPER RESISTOR >
JR803 1-216-864-11 SHORT CHIP 0
JR805 1-216-864-11 SHORT CHIP 0
JR806 1-216-864-11 SHORT CHIP 0
< TRANSISTOR >
Q801 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q802 8-729-120-28 TRANSISTOR 2SC1623-L5L6
< RESISTOR >
R805 1-216-833-11 METAL CHIP 10K 5% 1/10W
R806 1-216-833-11 METAL CHIP 10K 5% 1/10W
R807 1-216-833-11 METAL CHIP 10K 5% 1/10W
R808 1-216-845-11 METAL CHIP 100K 5% 1/10W
R809 1-216-821-11 METAL CHIP 1K 5% 1/10W
R810 1-216-837-11 METAL CHIP 22K 5% 1/10W
R811 1-216-809-11 METAL CHIP 100 5% 1/10W
R812 1-216-845-11 METAL CHIP 100K 5% 1/10W
R813 1-216-809-11 METAL CHIP 100 5% 1/10W
R814 1-216-849-11 METAL CHIP 220K 5% 1/10W
R815 1-216-833-11 METAL CHIP 10K 5% 1/10W
R816 1-216-833-11 METAL CHIP 10K 5% 1/10W
R817 1-216-821-11 METAL CHIP 1K 5% 1/10W
R818 1-216-834-11 METAL CHIP 12K 5% 1/10W
R819 1-216-837-11 METAL CHIP 22K 5% 1/10W
R820 1-216-837-11 METAL CHIP 22K 5% 1/10W
R821 1-216-833-11 METAL CHIP 10K 5% 1/10W
R822 1-216-833-11 METAL CHIP 10K 5% 1/10W
R823 1-216-833-11 METAL CHIP 10K 5% 1/10W
R824 1-216-833-11 METAL CHIP 10K 5% 1/10W
R825 1-216-805-11 METAL CHIP 47 5% 1/10W
R826 1-218-285-11 METAL CHIP 75 5% 1/10W
R827 1-216-821-11 METAL CHIP 1K 5% 1/10W
R828 1-216-841-11 METAL CHIP 47K 5% 1/10W
R829 1-216-837-11 METAL CHIP 22K 5% 1/10W
R830 1-216-845-11 METAL CHIP 100K 5% 1/10W
R831 1-216-845-11 METAL CHIP 100K 5% 1/10W
R832 1-216-821-11 METAL CHIP 1K 5% 1/10W
R833 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R891 1-216-837-11 METAL CHIP 22K 5% 1/10W
R892 1-216-837-11 METAL CHIP 22K 5% 1/10W
R893 1-216-837-11 METAL CHIP 22K 5% 1/10W
R894 1-216-846-11 METAL CHIP 120K 5% 1/10W
R895 1-216-178-00 RES-CHIP 150 5% 1/8W
R896 1-216-837-11 METAL CHIP 22K 5% 1/10W
R897 1-216-837-11 METAL CHIP 22K 5% 1/10W
R898 1-216-837-11 METAL CHIP 22K 5% 1/10W
R899 1-216-841-11 METAL CHIP 47K 5% 1/10W
< VARIABLE RESISTOR >
VR801 1-223-983-11 RES, VAR, CARBON 50K (MIC LEVEL)
VR802 1-223-983-11 RES, VAR, CARBON 50K (ECHO LEVEL)
*************************************************************
1-687-133-12 MOTOR (LD) BOARD
*****************
*************************************************************
MIC MOTOR (LD)
