82
HCD-RV22/RV55
VIDEO OUT BOARD
****************
< CAPACITOR >
C840 1-164-156-11 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
CN805 1-564-704-11 PIN, CONNECTOR (SMALL TYPE) 2P
< JACK >
J803 1-774-227-11 JACK, PIN 1P (VIDEO OUT)
*************************************************************
A-1079-677-A VMP43GY BOARD, COMPLETE (RV22:EA)
A-4752-391-A VMP43GY BOARD, COMPLETE (EXCEPT RV22:EA)
*************************
< CAPACITOR >
C104 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C105 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C106 1-164-670-11 CERAMIC CHIP 1200PF 5% 16V
C114 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C115 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C116 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C154 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C155 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C156 1-164-670-11 CERAMIC CHIP 1200PF 5% 16V
C201 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C202 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C203 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C204 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C205 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C206 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C207 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C208 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C209 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C210 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C211 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C212 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C213 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C214 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C221 1-124-779-00 ELECT CHIP 10uF 20% 16V
C222 1-124-779-00 ELECT CHIP 10uF 20% 16V
C223 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C224 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C253 1-216-864-11 SHORT CHIP 0
C254 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(EXCEPT RV22:EA)
C255 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(EXCEPT RV22:EA)
C257 1-128-065-11 ELECT CHIP 68uF 20% 10V
C258 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C259 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C321 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C322 1-162-917-11 CERAMIC CHIP 15PF 5% 50V
C323 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C338 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C360 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C361 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(RV22:EA)
C361 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(EXCEPT RV22:EA)
C362 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
(EXCEPT RV22:EA)
C362 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
(RV22:EA)
C364 1-124-779-00 ELECT CHIP 10uF 20% 16V
C365 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C366 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C501 1-124-779-00 ELECT CHIP 10uF 20% 16V
C502 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C503 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C504 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C505 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C510 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C511 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C513 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C521 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C522 1-162-912-11 CERAMIC CHIP 7PF 0.5PF 50V
C523 1-162-912-11 CERAMIC CHIP 7PF 0.5PF 50V
C524 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C525 1-126-193-11 ELECT CHIP 1uF 20% 50V
C533 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C534 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C535 1-110-563-11 CERAMIC CHIP 0.068uF 10% 16V
C536 1-164-217-11 CERAMIC CHIP 150PF 5% 50V
C537 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C538 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C539 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V
C540 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C541 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C542 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C543 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C544 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V
C545 1-126-193-11 ELECT CHIP 1uF 20% 50V
C546 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C547 1-126-193-11 ELECT CHIP 1uF 20% 50V
C548 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C549 1-162-913-11 CERAMIC CHIP 8PF 0.5PF 50V
C550 1-162-913-11 CERAMIC CHIP 8PF 0.5PF 50V
C551 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C552 1-126-193-11 ELECT CHIP 1uF 20% 50V
C561 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(RV22:EA)
C561 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(EXCEPT RV22:EA)
C566 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C567 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C570 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C571 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(RV22:EA)
C571 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(EXCEPT RV22:EA)
C572 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C573 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(RV22:EA)
C573 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(EXCEPT RV22:EA)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
