HCD-RV22/RV55
R561 1-216-821-11 METAL CHIP 1K 5% 1/10W
R581 1-216-809-11 METAL CHIP 100 5% 1/10W
R582 1-216-817-11 METAL CHIP 470 5% 1/10W
< VIBRATOR >
X501 1-767-518-11 VIBRATOR, CRYSTAL (32.8688MHz)
X502 1-767-519-11 VIBRATOR, CRYSTAL (27MHz)
*************************************************************
6 STREAM LED BOARD
*******************
< DIODE >
LED610 6-500-809-01 LED SELU5223C-STP15 (ILLUMINATION)
LED611 6-500-809-01 LED SELU5223C-STP15 (ILLUMINATION)
LED612 6-500-809-01 LED SELU5223C-STP15 (ILLUMINATION)
LED613 6-500-809-01 LED SELU5223C-STP15 (ILLUMINATION)
LED614 6-500-809-01 LED SELU5223C-STP15 (ILLUMINATION)
LED615 6-500-809-01 LED SELU5223C-STP15 (ILLUMINATION)
< RESISTOR >
R673 1-216-837-11 METAL CHIP 22K 5% 1/10W
R699 1-216-182-00 RES-CHIP 220 5% 1/8W
R701 1-216-182-00 RES-CHIP 220 5% 1/8W
R703 1-216-182-00 RES-CHIP 220 5% 1/8W
R705 1-216-182-00 RES-CHIP 220 5% 1/8W
R707 1-216-182-00 RES-CHIP 220 5% 1/8W
R709 1-216-182-00 RES-CHIP 220 5% 1/8W
< ROTARY ENCODER >
S660 1-418-632-11 ENCODER, ROTARY (MASTER VOLUME)
< SWITCH >
SW601 1-786-289-11 SWITCH, DETECTION (l – EQ + L)
*************************************************************
Ref. No. Part No. Description Remark
MISCELLANEOUS
***************
6 1-769-940-11 WIRE (FLAT TYPE) (11 CORE)
52 1-796-485-41 DECK, MECHANICAL (RV22)
52 1-796-487-51 DECK, MECHANICAL (RV55)
60 1-769-975-11 WIRE (FLAT TYPE) (13 CORE)
61 1-765-325-11 WIRE (FLAT TYPE) (11 CORE)
0 206 1-751-520-11 CORD, POWER (EA)
0 206 1-777-071-83 CORD, POWER (PH,SP,MY)
0 206 1-791-901-12 CORD, POWER (E3,E15)
0 206 1-824-818-11 CORD, POWER (WITH CONNECTOR) (TH)
259 1-776-182-11 WIRE (FLAT TYPE) (5 CORE)
352 1-471-035-11 MAGNET ASSY
364 1-775-265-11 WIRE (FLAT TYPE) (29 CORE)
0 402 8-820-122-01 OPTICAL PICK-UP (KSM-213DHAP/Z-RP)
403 1-782-817-11 WIRE (FLAT TYPE) (16 CORE)
0 F904 1-533-473-12 FUSE, GLASS TUBE (DIA.5) (6.3A/250V) (RV55)
0 F904 1-576-655-12 FUSE, GLASS TUBE (DIA.5) (8A/250V) (RV22)
0 F905 1-533-473-12 FUSE, GLASS TUBE (DIA.5) (6.3A/250V) (RV55)
0 F905 1-576-655-12 FUSE, GLASS TUBE (DIA.5) (8A/250V) (RV22)
0 F906 1-533-470-12 FUSE, GLASS TUBE (DIA.5) (3.15A/250V)
0 F907 1-533-470-12 FUSE, GLASS TUBE (DIA.5) (3.15A/250V)
0 F908 1-576-655-12 FUSE, GLASS TUBE (DIA.5) (8A/250V) (RV55)
0 F909 1-576-655-12 FUSE, GLASS TUBE (DIA.5) (8A/250V) (RV55)
FAN901 1-763-072-11 FAN, DC (E3,E15,PH)
FB901 1-400-285-11 F-BEAD, E2515MRT (RV22:EA)
FC901 1-500-386-31 FILTER, CLAMP (FERRITE CORE)
M741 A-4723-963-A MOTOR ASSY, TABLE (TABLE)
M751 A-4737-553-A MOTOR ASSY, LOADING (LOADING)
0 PT901 1-443-237-11 TRANSFORMER, POWER (RV22:EXCEPT EA)
0 PT901 1-443-255-11 TRANSFORMER, POWER (RV55:EXCEPT EA)
0 PT901 1-443-281-11 TRANSFORMER, POWER (RV55:EA)
0 PT901 1-443-282-11 TRANSFORMER, POWER (RV22:EA)
0 PT902 X-4956-294-1 TRANS ASSY, SUB (EXCEPT EA)
0 PT902 X-4956-322-1 TRANS ASSY, SUB (EA)
RE701 1-477-680-12 ENCODER, ROTARY
TM901 1-693-603-31 TUNER (FM/AM) (ANTENNA)
Ref. No. Part No. Description Remark
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
