– 115 –
< GROUND TERMINAL >
* EPT901 4-870-539-11 PLATE, GROUND
< COIL >
FB381 1-414-234-11 INDUCTOR CHIP 0UH
< FILTER >
FL131 1-233-289-21 FILTER, EMI (SMD)
FL241 1-233-289-21 FILTER, EMI (SMD)
FL501 1-233-289-21 FILTER, EMI (SMD)
FL502 1-233-289-21 FILTER, EMI (SMD)
< IC >
IC111 8-759-495-24 IC M62442FP-TP
IC191 8-759-636-55 IC M5218AFP
IC201 8-759-526-39 IC LV1041M
IC291 8-759-636-55 IC M5218AFP
IC301 8-759-495-26 IC HA12215
IC391 8-749-923-04 IC TOTX178 (CD DIGITAL OUT OPTICAL)
IC401 8-759-636-55 IC M5218AFP
IC411 8-759-636-55 IC M5218AFP
IC501 8-759-537-36 IC uPD780018AYGF-012-3BA
IC901 8-759-604-86 IC M5F7807L
IC902 8-759-604-90 IC M5F7907L
IC911 8-759-231-58 IC TA7812S
IC921 8-759-604-38 IC M5F78M10
IC931 8-759-231-53 IC TA7805S
IC941 8-759-604-86 IC M5F7807L
IC951 8-759-635-63 IC M51943BSL
< JACK >
J101 1-774-411-11 JACK, PIN 6P
(VIDEO(AUDIO) IN, MD IN, MD/VIDEO (AUDIO) OUT)
J191 1-774-785-11 JACK, PIN 1P (SUPER WOOFER)
< JUMPER RESISTOR >
JR1 1-216-295-91 SHORT 0
JR2 1-216-295-91 SHORT 0
JR4 1-216-295-91 SHORT 0
JR5 1-216-295-91 SHORT 0
JR201 1-216-296-91 SHORT 0
JR202 1-216-296-91 SHORT 0
< COIL >
L241 1-412-032-11 INDUCTOR CHIP 100uH
L371 1-412-032-11 INDUCTOR CHIP 100uH (RX110AV:AEP,UK,G)
L372 1-412-032-11 INDUCTOR CHIP 100uH
L391 1-412-032-11 INDUCTOR CHIP 100uH
L569 1-412-032-11 INDUCTOR CHIP 100uH
L570 1-412-032-11 INDUCTOR CHIP 100uH
L572 1-412-032-11 INDUCTOR CHIP 100uH
< TRANSISTOR >
Q111 8-729-119-78 TRANSISTOR 2SC403SP-51
Q112 8-729-119-78 TRANSISTOR 2SC403SP-51
Q113 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q141 8-729-422-57 TRANSISTOR UN4111
Q142 8-729-900-36 TRANSISTOR DTC124ES
Q143 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q161 8-729-119-78 TRANSISTOR 2SC403SP-51
Q162 8-729-119-78 TRANSISTOR 2SC403SP-51
Q163 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q191 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q291 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q292 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q331 8-729-118-00 TRANSISTOR 2SB1116-L
Q332 8-729-900-80 TRANSISTOR DTC114ES
Q333 8-729-118-00 TRANSISTOR 2SB1116-L
Q334 8-729-900-80 TRANSISTOR DTC114ES
Q335 8-729-900-80 TRANSISTOR DTC114ES
Q336 8-729-116-57 TRANSISTOR 2SB1068-K
Q337 8-729-144-44 TRANSISTOR 2SD1513
Q338 8-729-422-57 TRANSISTOR UN4111
Q339 8-729-900-80 TRANSISTOR DTC114ES
Q340 8-729-166-57 TRANSISTOR 2SB1068-K
Q341 8-729-144-44 TRANSISTOR 2SD1513
Q342 8-729-422-57 TRANSISTOR UN4111
Q343 8-729-900-80 TRANSISTOR DTC114ES
Q411 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q901 8-729-040-20 TRANSISTOR RT1P137L-TP
Q902 8-729-900-36 TRANSISTOR DTC124ES
Q903 8-729-040-19 TRANSISTOR RT1N137L-TP
Q904 8-729-900-63 TRANSISTOR DTA124ES
Q905 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q911 8-729-141-83 TRANSISTOR 2SB1094-LK
Q912 8-729-900-36 TRANSISTOR DTC124ES
Q913 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q931 8-729-040-20 TRANSISTOR RT1P137L-TP
Q932 8-729-900-36 TRANSISTOR DTC124ES
Q933 8-729-040-20 TRANSISTOR RT1P137L-TP
Q934 8-729-900-63 TRANSISTOR DTA124ES
Q937 8-729-900-36 TRANSISTOR DTC124ES
Q951 8-729-119-78 TRANSISTOR 2SC403SP-51
Q961 8-729-111-29 TRANSISTOR 2SD1616A-K
Q962 8-729-119-76 TRANSISTOR 2SA1175-HFE
< RESISTOR >
R101 1-216-049-91 RES,CHIP 1K 5% 1/10W
R102 1-216-105-91 RES,CHIP 220K 5% 1/10W
R103 1-216-049-91 RES,CHIP 1K 5% 1/10W
R104 1-216-105-91 RES,CHIP 220K 5% 1/10W
R105 1-216-049-91 RES,CHIP 1K 5% 1/10W
R106 1-216-097-91 RES,CHIP 100K 5% 1/10W
R111 1-216-073-00 METAL CHIP 10K 5% 1/10W
R112 1-216-121-91 RES,CHIP 1M 5% 1/10W
R113 1-216-111-00 METAL CHIP 390K 5% 1/10W
R114 1-216-044-00 METAL CHIP 620 5% 1/10W
R115 1-216-073-00 METAL CHIP 10K 5% 1/10W
R116 1-216-097-91 RES,CHIP 100K 5% 1/10W
R117 1-216-073-00 METAL CHIP 10K 5% 1/10W
R118 1-216-089-91 RES,CHIP 47K 5% 1/10W
R119 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
To Next Page
