– 118 –
* 1-668-270-11 MIC BOARD
**********
< CAPACITOR >
C752 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C754 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C755 1-126-961-11 ELECT 2.2uF 20% 50V
C756 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C757 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C758 1-126-964-11 ELECT 10uF 20% 50V
C759 1-126-957-11 ELECT 0.22uF 20% 50V
C760 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C761 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C762 1-126-961-11 ELECT 2.2uF 20% 50V
C764 1-126-964-11 ELECT 10uF 20% 50V
C782 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
< FILTER >
FL751 1-233-289-21 FILTER, CHIP EMI
< IC >
IC750 8-759-636-55 IC M5218AFP
< JACK >
J751 1-784-224-11 JACK (LARGE TYPE) (MIX MIC)
< RESISTOR >
R750 1-216-073-00 METAL CHIP 10K 5% 1/10W
R751 1-216-049-91 RES,CHIP 1K 5% 1/10W
R752 1-216-097-91 RES,CHIP 100K 5% 1/10W
R753 1-216-049-91 RES,CHIP 1K 5% 1/10W
R754 1-216-081-00 METAL CHIP 22K 5% 1/10W
R755 1-216-073-00 METAL CHIP 10K 5% 1/10W
R756 1-216-103-00 METAL CHIP 180K 5% 1/10W
R757 1-216-025-91 RES,CHIP 100 5% 1/10W
< VARIABLE RESISTOR >
RV750 1-225-587-11 RES, VAR 50K (MIC LEVEL)
<CONNECTOR>
* W751 1-690-880-31 LEAD (WITH CONNECTOR)
**************************************************************
* 1-658-577-11 MOTOR (TURN) BOARD
*******************
< CAPACITOR >
C701 1-162-306-11 CERAMIC 0.01uF 20% 16V
C702 1-126-964-11 ELECT 10uF 20% 50V
C705 1-162-306-11 CERAMIC 0.01uF 20% 16V
< CONNECTOR >
CN703 1-750-413-11 CONNECTOR, FFC/FPC 8P
CN704 1-506-469-11 PIN, CONNECTOR 4P
< DIODE >
D701 8-719-109-69 DIODE RD3.6ES-B2
< IC >
IC701 8-759-633-65 IC M54641L
< RESISTOR >
R706 1-249-411-11 CARBON 330 5% 1/4W
R707 1-249-401-11 CARBON 47 5% 1/4W F
************************************************************
* 1-658-578-11 MOTOR (SLIDE) BOARD
*******************
< CAPACITOR >
C801 1-162-306-11 CERAMIC 0.01uF 20% 16V
C804 1-162-306-11 CERAMIC 0.01uF 20% 16V
C805 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
* CN801 1-568-947-11 PIN, CONNECTOR 9P
< DIODE >
D801 8-719-010-43 DIODE UZ-5.6BSC
D804 8-719-911-19 DIODE 1SS119
D805 8-719-911-19 DIODE 1SS119
< IC >
IC801 8-759-274-09 IC BA6286N
< RESISTOR >
R801 1-249-401-11 CARBON 47 5% 1/4W F
< SWITCH >
S801 1-762-527-11 SWITCH, ROTARY
************************************************************
* A-4407-266-A PANEL BOARD, COMPLETE (RX110AV:AEP,UK,G)
*********************
* A-4407-312-A PANEL BOARD, COMPLETE
*********************
(GRX10AV/RX110AV:CND,EE,CIS)
* 4-932-810-31 CUSHION (FL)
* 4-996-796-01 HOLDER, FL TUBE
< CAPACITOR >
C600 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C601 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C602 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C603 1-124-589-11 ELECT 47uF 20% 16V
C604 1-126-163-11 ELECT 4.7uF 20% 50V
C605 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C606 1-126-160-11 ELECT 1uF 20% 50V
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MOTOR (TURN) MOTOR (SLIDE)
MIC PANEL
To Next Page
