– 83 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
CD SW CONNECTOR
R161 1-216-308-00 METAL CHIP 4.7 5% 1/10W
R162 1-216-101-00 METAL CHIP 150K 5% 1/10W
R171 1-216-078-00 RES,CHIP 16K 5% 1/10W
R172 1-216-073-00 METAL CHIP 10K 5% 1/10W
R173 1-216-077-00 METAL CHIP 15K 5% 1/10W
R181 1-216-078-00 RES,CHIP 16K 5% 1/10W
R182 1-216-073-00 METAL CHIP 10K 5% 1/10W
R183 1-216-077-00 METAL CHIP 15K 5% 1/10W
< NETWORK >
RN101 1-233-576-11 RES, CHIP NETWORK 100
RN102 1-233-576-11 RES, CHIP NETWORK 100
< SWITCH >
S101 1-572-085-11 SWITCH, LEAF (LIMIT IN SW)
< VIBRATOR >
X101 1-767-408-21 VIBRATOR, CRYSTAL (16.9344MHz)
**************************************************************
* A-4417-663-A CD SW BOARD, COMPLETE
*********************
< DIODE >
D801 8-719-056-13 DIODE SML79423C-TP15
(DISC 1, DISC IN/PLAY)
D802 8-719-056-13 DIODE SML79423C-TP15
(DISC 2, DISC IN/PLAY)
D803 8-719-056-13 DIODE SML79423C-TP15
(DISC 3, DISC IN/PLAY)
D804 8-719-063-93 DIODE SLR325VC-N-T32
((STANDBY) POWER SAVE/DEMO)
< RESISTOR >
R801 1-216-049-91 RES,CHIP 1K 5% 1/10W
R802 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
R803 1-216-055-00 METAL CHIP 1.8K 5% 1/10W
R804 1-216-059-00 METAL CHIP 2.7K 5% 1/10W
R805 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R806 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R807 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R808 1-216-022-00 METAL CHIP 75 5% 1/10W
R809 1-216-029-00 METAL CHIP 150 5% 1/10W
R810 1-216-022-00 METAL CHIP 75 5% 1/10W
R811 1-216-029-00 METAL CHIP 150 5% 1/10W
R812 1-216-022-00 METAL CHIP 75 5% 1/10W
R813 1-216-029-00 METAL CHIP 150 5% 1/10W
R814 1-216-043-91 RES,CHIP 560 5% 1/10W
< SWITCH >
S801 1-762-875-21 SWITCH, KEYBOARD (1/u)
S802 1-762-875-21 SWITCH, KEYBOARD
((STANDBY) POWER SAVE/DEMO)
S803 1-762-875-21 SWITCH, KEYBOARD (DISC 1)
S804 1-762-875-21 SWITCH, KEYBOARD (DISC 2)
S805 1-762-875-21 SWITCH, KEYBOARD (DISC 3)
S806 1-762-875-21 SWITCH, KEYBOARD (DISC SKIP/EX-CHANGE)
S807 1-762-875-21 SWITCH, KEYBOARD (§)
**************************************************************
* 1-658-575-11 CONNECTOR BOARD
*****************
< CONNECTOR >
* CN701 1-568-946-11 PIN, CONNECTOR 8P
CN702 1-750-413-11 CONNECTOR, FFC/FPC 8P
< TRANSISTOR >
Q701 8-729-900-80 TRANSISTOR DTC114ES
< RESISTOR >
R703 1-249-435-11 CARBON 33K 5% 1/4W
R704 1-249-429-11 CARBON 10K 5% 1/4W
R705 1-249-417-11 CARBON 1K 5% 1/4W F
**************************************************************
* A-2007-732-A LEAF SW BOARD, COMPLETE
************************
< CAPACITOR >
C1001 1-107-716-11 ELECT 33uF 20% 10V
< CONNECTOR >
CN1001 1-568-860-11 SOCKET, CONNECTOR 17P
CN1001 1-784-459-11 CONNECTOR, FFC/FPC 17P
< DIODE >
D1001 8-719-911-19 DIODE 1SS119
D1002 8-719-911-19 DIODE 1SS119
< HOLDER >
* DM1001 1-784-581-11 HOLDER, CABLE (2.5MM PITCH) 4P
< IC >
IC1001 8-749-014-38 IC PHOTO INTERRUPTER SG-264
IC1002 8-749-014-38 IC PHOTO INTERRUPTER SG-264
< TRANSISTOR >
Q1001 8-729-029-56 TRANSISTOR DTA144ESA
< RESISTOR >
R907 1-247-879-11 CARBON 100K 5% 1/4W
R1001 1-249-409-11 CARBON 220 5% 1/4W F
R1002 1-249-409-11 CARBON 220 5% 1/4W F
R1003 1-249-414-11 CARBON 560 5% 1/4W F
R1004 1-247-834-11 CARBON 1.3K 5% 1/4W
R1005 1-247-818-11 CARBON 300 5% 1/4W
R1006 1-247-864-11 CARBON 24K 5% 1/4W
R1007 1-247-856-00 CARBON 11K 5% 1/4W
R1008 1-249-417-11 CARBON 1K 5% 1/4W F
BD LEAF SW
