88
HCD-S500/S800
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
R984 1-218-965-11 RES-CHIP 10K 5% 1/16W
R985 1-218-985-11 RES-CHIP 470K 5% 1/16W
R986 1-218-973-11 RES-CHIP 47K 5% 1/16W
R987 1-218-973-11 RES-CHIP 47K 5% 1/16W
R988 1-218-990-11 SHORT 0
R989 1-218-990-11 SHORT 0
R990 1-218-965-11 RES-CHIP 10K 5% 1/16W
R991 1-218-965-11 RES-CHIP 10K 5% 1/16W
R992 1-218-965-11 RES-CHIP 10K 5% 1/16W
< VARIABLE RESISTOR >
RV501 1-223-583-11 RES, ADJ, CARBON 1K
< VIBRATOR >
X101 1-795-174-11 VIBRATOR, CERAMIC (16.5MHz)
X102 1-781-867-21 VIBRATOR, CRYSTAL (27MHz)
(S800:EA,HK,TW,AUS)
X102 1-767-519-11 VIBRATOR, CRYSTAL (29MHz)
(S500/S800:AEP,CIS,UK)
X600 1-795-126-11 VIBRATOR, CRYSTAL (12.288MHz)
X601 1-795-363-21 VIBRATOR, CERAMIC (13.5MHz)
X901 1-767-922-11 VIBRATOR, CERAMIC (16MHz)
************************************************************
A-4726-419-A FP-1030 BOARD, COMPLETE
***********************
4-234-908-01 HOLDER (FL) (EXCEPT S500:AEP,UK,KR)
< CAPACITOR >
C812 1-126-153-11 ELECT 22uF 20% 6.3V
(EXCEPT S500:AEP,UK,KR)
C812 1-126-514-11 ELECT 22uF 20.00% 6.3V
(S500:AEP,UK,KR)
C813 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C814 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C815 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C816 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C817 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C818 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C819 1-164-360-11 CERAMIC CHIP 0.1uF 16V
< CONNECTOR >
CN801 1-785-414-11 CONNECTOR, FFC/FPC 15P
CN802 1-506-481-11 PIN, CONNECTOR 2P
CN804 1-568-955-11 PIN, CONNECTOR 6P
* CN813 1-568-941-11 PIN, CONNECTOR 3P
< FERRITE BEAD >
FB800 1-414-813-11 FERRITE 0uH
FB801 1-414-813-11 FERRITE 0uH
FB802 1-414-813-11 FERRITE 0uH
< FILTER >
FL801 1-518-767-21 INDICATOR TUBE, FLUORESCENT
< IC >
IC802 6-700-112-01 IC MSM9202-05GS-KDR1
< TRANSISTOR >
Q801 8-729-602-36 TRANSISTOR 2SA1602TP-1EF
< RESISTOR >
R805 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R838 1-216-805-11 METAL CHIP 47 5% 1/16W
R840 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R841 1-216-809-11 METAL CHIP 100 5% 1/16W
R842 1-216-809-11 METAL CHIP 100 5% 1/16W
R843 1-216-809-11 METAL CHIP 100 5% 1/16W
************************************************************
1-681-991-11 FU-1030 BOARD
*************
< CAPACITOR >
C800 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C801 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
< RESISTOR >
R809 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R837 1-216-821-11 METAL CHIP 1K 5% 1/16W
R844 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R849 1-216-824-11 METAL CHIP 1.8K 5% 1/16W
R860 1-216-826-11 METAL CHIP 2.7K 5% 1/16W
R864 1-216-841-11 METAL CHIP 47K 5% 1/16W
(S500:AEP,UK,KR)
R864 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
(EXCEPT S500:AEP,UK,KR)
R873 1-216-809-11 METAL CHIP 100 5% 1/16W
< SWITCH >
S800 1-418-632-11 ENCODER, ROTARY (VOLUME)
S821 1-762-875-21 SWITCH, KEYBOARD (SOUND FIELD +)
S822 1-762-875-21 SWITCH, KEYBOARD (SOUND FIELD -)
S823 1-762-875-21 SWITCH, KEYBOARD (DISPLAY)
S824 1-762-875-21 SWITCH, KEYBOARD (BAND)
S825 1-762-875-21 SWITCH, KEYBOARD (FUNCTION)
************************************************************
1-681-996-11 HP-1030 BOARD
*************
< CAPACITOR >
C900 1-124-234-00 ELECT 22uF 20% 16V
C901 1-124-234-00 ELECT 22uF 20% 16V
C902 1-163-011-11 CERAMIC CHIP 0.0015uF 10% 50V
C903 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C904 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
< JACK >
J900 1-566-891-21 JACK (PHONES)
< COIL >
L900 1-410-387-11 INDUCTOR CHIP 33uH
L901 1-410-387-11 INDUCTOR CHIP 33uH
DVD FP-1030 FU-1030 HP-1030
