Sony HCD-S500 - Page 91

89
HCD-S500/S800
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
< TRANSISTOR >
Q900 8-729-046-97 TRANSISTOR 2SD1938(F)-T(TX).SO
Q901 8-729-046-97 TRANSISTOR 2SD1938(F)-T(TX).SO
< RESISTOR >
R900 1-216-833-11 METAL CHIP 10K 5% 1/16W
R901 1-216-821-11 METAL CHIP 1K 5% 1/16W
R902 1-216-833-11 METAL CHIP 10K 5% 1/16W
R903 1-216-821-11 METAL CHIP 1K 5% 1/16W
R905 1-216-821-11 METAL CHIP 1K 5% 1/16W
R906 1-216-821-11 METAL CHIP 1K 5% 1/16W
************************************************************
A-4726-402-A I/O BOARD, COMPLETE
(EXCEPT S500:AEP,CIS,UK/S800)
*******************
A-4726-592-A I/O BOARD, COMPLETE (S500:CIS/S800)
*******************
A-4726-827-A I/O BOARD, COMPLETE (S500:AEP,UK)
*******************
< CAPACITOR >
C600 1-126-956-11 ELECT 0.1uF 20.00% 50V
(S500:AEP,UK)
C600 1-128-551-11 ELECT 22uF 20.00% 25V
(EXCEPT S500:AEP,UK)
C601 1-126-956-11 ELECT 0.1uF 20.00% 50V
(S500:AEP,UK)
C601 1-128-551-11 ELECT 22uF 20.00% 25V
(EXCEPT S500:AEP,UK)
C602 1-126-933-11 ELECT 100uF 20.00% 16V
C603 1-126-960-11 ELECT 1uF 20.00% 50V
C604 1-126-960-11 ELECT 1uF 20.00% 50V
C605 1-163-038-00 CERAMIC CHIP 0.1uF 25V
(S500:AEP,UK)
C605 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(EXCEPT S500:AEP,UK)
C606 1-163-038-00 CERAMIC CHIP 0.1uF 25V
(S500:AEP,UK)
C606 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(EXCEPT S500:KR)
C608 1-163-023-00 CERAMIC CHIP 0.015uF 5% 50V
(S500:AEP,UK,)
C608 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
(EXCEPT S500:AEP,UK)
C609 1-163-023-00 CERAMIC CHIP 0.015uF 5% 50V
(S500:AEP,UK)
C609 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
(EXCEPT S500:AEP,UK)
C610 1-126-956-11 ELECT 0.1uF 20.00% 50V
(S500:AEP,UK)
C610 1-128-551-11 ELECT 22uF 20.00% 25V
(EXCEPT S500:AEP,UK)
C611 1-126-956-11 ELECT 0.1uF 20.00% 50V
(S500:AEP,UK)
C611 1-128-551-11 ELECT 22uF 20.00% 25V
(EXCEPT S500:AEP,UK)
C612 1-126-933-11 ELECT 100uF 20.00% 16V
(S500:AEP,UK)
C613 1-126-956-11 ELECT 0.1uF 20.00% 50V
(S500:AEP,UK)
C613 1-128-551-11 ELECT 22uF 20.00% 25V
(EXCEPT S500:AEP,UK)
C614 1-163-038-00 CERAMIC CHIP 0.1uF 25V
(S500:AEP,UK)
C614 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(EXCEPT S500:AEP,UK)
C615 1-126-956-11 ELECT 0.1uF 20.00% 50V
(S500:AEP,UK)
C615 1-128-551-11 ELECT 22uF 20.00% 25V
(EXCEPT S500:AEP,UK)
C616 1-126-956-11 ELECT 0.1uF 20.00% 50V
(S500:AEP,UK)
C616 1-128-551-11 ELECT 22uF 20.00% 25V
(EXCEPT S500:AEP,UK)
C617 1-163-038-00 CERAMIC CHIP 0.1uF 25V
(S500:AEP,UK)
C617 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(EXCEPT S500:AEP,UK)
C618 1-126-956-11 ELECT 0.1uF 20.00% 50V
(S500:AEP,UK)
C618 1-128-551-11 ELECT 22uF 20.00% 25V
(EXCEPT S500:AEP,UK)
C619 1-126-956-11 ELECT 0.1uF 20.00% 50V
(S500:AEP,UK)
C619 1-128-551-11 ELECT 22uF 20.00% 25V
(EXCEPT S500:AEP,UK)
C620 1-126-956-11 ELECT 0.1uF 20.00% 50V
(S500:AEP,UK)
C620 1-128-551-11 ELECT 22uF 20.00% 25V
(EXCEPT S500:AEP,UK)
C621 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
(EXCEPT S500:AEP,UK)
C621 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
(S500:AEP,UK)
C622 1-126-956-11 ELECT 0.1uF 20.00% 50V
(S500:AEP,UK)
C622 1-128-551-11 ELECT 22uF 20.00% 25V
(EXCEPT S500:AEP,UK)
C623 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
(EXCEPT S500:AEP,UK)
C623 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
(S500:AEP,UK)
C624 1-126-956-11 ELECT 0.1uF 20.00% 50V
(S500:AEP,UK)
C624 1-128-551-11 ELECT 22uF 20.00% 25V
(EXCEPT S500:AEP,UK)
C625 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
(EXCEPT S500:AEP,UK)
C625 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
(S500:AEP,UK)
C626 1-128-551-11 ELECT 22uF 20.00% 25V
(EXCEPT S500:AEP,UK)
C626 1-126-956-11 ELECT 0.1uF 20.00% 50V
(S500:AEP,UK)
C627 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
(EXCEPT S500:AEP,UK)
C627 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
(S500:AEP,UK)
I/OHP-1030
