Sony HCD-S550 - Page 137

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
137
HCD-S550/S880
SWITCH BOARD
**************
< SWITCH >
S731 1-786-289-21 SWITCH, DETECTION (DISC SIZE)
**************************************************************
1-685-084-11 VOL BOARD
**********
< CAPACITOR >
C800 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C801 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
< CONNECTOR >
* CN820 1-568-941-11 PIN, CONNECTOR 3P
< SWITCH >
S800 1-418-632-11 ENCODER, ROTARY (VOLUME)
**************************************************************
MISCELLANEOUS
**************
152 1-824-477-11 FLEXIBLE FLAT CABLE (17 CORE)
153 1-824-475-11 FLEXIBLE FLAT CABLE (18 CORE)
154 1-824-476-11 FLEXIBLE FLAT CABLE (12 CORE)
155 1-824-624-11 FLEXIBLE FLAT CABLE (17 CORE)
156 1-824-474-11 FLEXIBLE FLAT CABLE (29 CORE)
157 1-824-473-11 FLEXIBLE FLAT CABLE (14 CORE)
158 1-687-072-11 PWB, FLEXIBLE
0 302 1-696-169-12 CORD, POWER
(AEP, UK, E, HK, EA, CIS, SP, MY, TW)
0 302 1-696-848-42 CORD, POWER (AUS)
0 302 1-769-079-22 CORD, POWER (KR)
0 302 1-775-789-91 CORD, POWER (MX)
0 302 1-782-464-22 CORD, POWER (CH)
305 1-824-486-11 FLEXIBLE FLAT CABLE (11 CORE)
0 703 1-477-263-11 PICKUP UNIT (TDP022W)
705 1-685-250-11 FLEXIBLE BOARD
0 F901 1-533-470-12 FUSE, GLASS TUBE (DIA. 5) (5A/125V)
M301 1-763-861-11 FAN, DC
M711 A-4746-746-A MOTOR (LD) ASSY (LOADING)
M751 A-4746-747-A MOTOR (CK) ASSY (EJECT)
SWITCH VOL
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
Ver 1.3
