HCD-S550/S880
ta IC602 qd (LRCK)
6.3 Vp-p
20.8 µs
ts IC602 qf (BCK)
5.9 Vp-
p
325 ns
3.7 Vp-p
20.8 µs
3.6 Vp-
p
325 ns
is IC305, 308, 310 rg (LRCK)
– AMP Board –
ia IC305, 308, 310 rf (BCK)
3.4 Vp-
p
81 ns
id IC305, 308, 310 yf (XFSIIN)
3.7 Vp-p
20.8 µs
if IC305 ud (FSOCKO)
3.5 Vp-
p
20 ns
ig IC305 uj (XFSOOUT)
3.3 Vp-
p
20 ns
ih IC300 4
