– 5 –
SECTION 2
GENERAL
LOCATION OF CONTROLS
• Front view
1 2
!§
!∞
@º
@¡
@™
@£
@¢
@∞
5
6
7
8
9
!º
!¡
!™
!£
!¢
#¢
#∞
#•
#ª
$º
@ª
#º
#¡
#™
#£
$¡ $™ $£ $¢ $∞ $§ $¶
1 I /u (Power) button
2 DISC 1 to 3 buttons and indicators
3 DISC SKIP/EX-CHANGE button
4 6 (CD) button
5 CD disc tray
6 CD ^ button and indicator
7 TUNER, BAND button
8 r REC button and indicator
9 P PAUSE button and indicator
!º HI-DUB button
!¡ CD SYNC button
!™ FILE SELECT button
!£ SURROUND button
!¢ KARAOKE PON/MPX button
!∞ DECK B 9 and ( buttons and indicators
!§ DECK A 9 and ( buttons and indicators
!¶ FUNCTION button
!• ECHO LEVEL knob
!ª MIC LEVEL knob
@º MIC1 jack
@¡ MIC2 jack
@™ DISPLAY/DEMO button
@£ CLOCK/TIMER SET button
@¢ TIMER SELECT button
@∞ p button
!ª
#¶
3 4
!•
!¶
@§ Fluorescent indicator tube
@¶ ENTER/NEXT button and indicator
@• ACTIVE, SELECT, RETURN, PREV, NEXT button
@ª VIDEO CD, PBC, PBC OFF indicators
#º GROOVE button and indicator
#¡ VOLUME konb
#™ PHONES jack
#£ DBFB button
#¢ Remote sensor
#∞ CD LOOP button
#§ CD NON-STOP button and indicator
#¶ CD FLASH button
#• EDIT, DIRECTION button
#ª PLAY MODE, DOLBY NR button
$º REPEAT button
$¡ § button (deck A)
$™ Tape deck A
$£ –, 0 button and indicator
$¢ JOG dial
$∞ +, ) button and indicator
$§ Tape deck B
$¶ § button (deck B)
@§ @¶ @•
#§
