ā 115 ā
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R921 1-216-073-00 METAL CHIP 10K 5% 1/10W
< VIBRATOR >
X101 1-767-518-11 VIBRATOR, CRYSTAL (33MHz)
X201 1-767-055-11 VIBRATOR, CERAMIC (45MHz)
X202 1-767-361-11 VIBRATOR, CERAMIC (28.63636MHz)
X401 1-767-519-11 VIBRATOR, CRYSTAL (27MHz)
X701 1-767-211-11 VIBRATOR, CERAMIC (10MHz)
X901 1-767-144-21 VIBRATOR, CERAMIC (5MHz)
************************************************************
* 1-665-406-11 VIDEO OUT BOARD
****************
< CAPACITOR >
C9001 1-126-926-11 ELECT 1000uF 20% 10V
C9002 1-126-926-11 ELECT 1000uF 20% 10V
C9003 1-126-925-11 ELECT 470uF 20% 10V
C9004 1-164-159-11 CERAMIC 0.1uF 50V
C9005 1-164-159-11 CERAMIC 0.1uF 50V
C9006 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
* CN9001 1-564-710-11 PIN, CONNECTOR (SMALL TYPE) 8P
< FERRITE BEAD >
FB9001 1-412-473-21 INDUCTOR 0UH
FB9002 1-412-473-21 INDUCTOR 0UH
FB9003 1-412-473-21 INDUCTOR 0UH
< PIN JACK/S TERMINAL >
J9001 1-774-227-11 JACK, PIN 1P (VIDEO OUT)
J9002 1-778-773-11 TERMINAL, S (S VIDEO OUT)
< RESISTOR >
R9001 1-249-429-11 CARBON 10K 5% 1/4W
R9002 1-249-429-11 CARBON 10K 5% 1/4W
R9003 1-249-429-11 CARBON 10K 5% 1/4W
R9004 1-249-429-11 CARBON 10K 5% 1/4W
R9005 1-249-433-11 CARBON 22K 5% 1/4W
< SWITCH >
S9001 1-571-589-11 SWITCH, SLIDE (SYSTEM SELECT)
************************************************************
* 1-666-126-11 VIDEO POWER BOARD
******************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACITOR >
C9001 1-126-964-11 ELECT 10uF 20% 50V
C9002 1-126-933-11 ELECT 100uF 20% 16V
C9003 1-126-929-11 ELECT 4700uF 20% 10V
C9004 1-126-964-11 ELECT 10uF 20% 50V
C9005 1-126-933-11 ELECT 100uF 20% 16V
C9006 1-126-933-11 ELECT 100uF 20% 16V
< CONNECTOR >
CN9001 1-564-506-11 PLUG, CONNECTOR 3P
* CN9002 1-564-507-11 PLUG, CONNECTOR 4P
< IC >
IC9001 8-759-231-53 IC TA7805S
IC9002 8-759-231-53 IC TA7805S
< TRANSISTOR >
Q9001 8-729-141-83 TRANSISTOR 2SB1094-LK
Q9002 8-729-900-36 TRANSISTOR DTC124ES
Q9003 8-729-141-83 TRANSISTOR 2SB1094-LK
Q9004 8-729-900-36 TRANSISTOR DTC124ES
< RESISTOR >
R9001 1-249-421-11 CARBON 2.2K 5% 1/4W
R9002 1-249-413-11 CARBON 470 5% 1/4W
R9003 1-249-421-11 CARBON 2.2K 5% 1/4W
R9004 1-249-413-11 CARBON 470 5% 1/4W
************************************************************
MISCELLANEOUS
**************
14 1-773-160-11 WIRE (FLAT TYPE) (21 CORE)
15 1-769-947-11 WIRE (FLAT TYPE) (11 CORE)
64 1-777-869-11 WIRE (FLAT TYPE) (10 CORE)
65 1-777-936-11 WIRE (FLAT TYPE) (5 CORE)
66 1-773-051-11 WIRE (FLAT TYPE) (17 CORE)
74 1-769-909-11 WIRE (FLAT TYPE) (9 CORE)
104 1-782-654-11 WIRE (FLAT TYPE) (29 CORE)
106 1-233-545-11 ENCAPSULATED COMPONENT
(FM/AM TUNER UNIT) (EA)
106 1-233-546-11 ENCAPSULATED COMPONENT
(FM/AM TUNER UNIT) (EXCEPT EA)
108 1-773-012-11 WIRE (FLAT TYPE) (15 CORE)
! 113 1-575-651-11 CORD, POWER (EA, MY, SP, HK, TW)
! 113 1-575-653-11 CORD, POWER (IA, JE)
! 113 1-751-326-31 CORD, POWER (TH)
! 113 1-782-464-21 CORD, POWER (CH)
! 114 1-569-007-11 ADAPTOR, CONVERSION 2P (IA, JE)
! 114 1-569-008-11 ADAPTOR, CONVERSION 2P (MY, SP, TW)
! 114 1-770-019-11 ADAPTOR, CONVERSION PLUG 3P (HK)
119 1-782-653-11 WIRE (FLAT TYPE) (13 CORE)
257 1-452-925-11 MAGNET ASSY
258 1-776-042-11 WIRE (FLAT TYPE) (8 CORE)
! 301 8-820-020-01 OPTICAL PICK-UP KSS-213D/Q-NP
302 1-769-069-11 WIRE (FLAT TYPE) (16 CORE)
HP101 1-500-093-11 HEAD, MAGNETIC (PLAYBACK) (DECK A)
HRPE1011-500-094-11 HEAD, MAGNETIC (REC/PB/ERASE) (DECK B)
M1 X-3371-223-1 MOTOR ASSY, CAPSTAN
M2 A-2004-410-A MOTOR ASSY, DC (TRIGGER)
M101 X-4917-523-4 MOTOR ASSY (SPINDLE)
M102 X-4917-504-1 MOTOR ASSY (SLED)
M701 A-4672-004-A MOTOR ASSY (TURN)
M801 A-4672-004-A MOTOR ASSY (SLIDE)
VIDEO VIDEO OUT VIDEO POWER
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
