– 116 –
HCD-V707
97G057015-1
Printed in Singapore © 1997. 7
Published by General Engineering Dept.
(Shibaura)
Sony Corporation
Home A&V Products Company
9-960-983-11
M901 1-698-792-11 FAN, DC
S811 1-473-335-11 ENCODER, ROTARY (BU, TRAY ADDRESS DET)
! T901 1-431-305-11 TRANSFORMER, POWER
************************************************************
**************
HARDWARE LIST
**************
#1 7-685-871-01 SCREW +BVTT 3X6 (S)
#2 7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
#3 7-685-650-79 SCREW +BVTP 3X16 TYPE2 IT-3
#4 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#5 7-621-775-10 SCREW +B 2.6X4
#6 7-621-255-15 SCREW +P 2X3
#7 7-685-533-19 SCREW +BTP 2.6X6 TYPE2 N-S
#8 7-685-131-19 SCREW +BTP 2.6X4 TYPE2 N-S
#9 7-685-862-09 SCREW +BVTT 2.6X6 (S)
#10 7-685-534-19 SCREW +BTP 2.6X8 TYPE2 N-S
#11 7-623-921-01 RING, RETAINING, CAPSTAN
#12 7-621-775-00 SCREW +B 2.6X3
#13 7-685-872-09 SCREW +BVTT 3X8 (S)
Ref. No. Part No. Description Remark
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
