– 10 –
BD BOARD
4
flat wire (16 core)
(CN102)
5
screw
(BVTP 2.6
×
8)
6
Removal
the four solders.
7
BD board
1
two screws
(PTPWH M2.6
×
6)
1
two screws
(PTPWH M2.6
×
6)
2
optical pick-up
section
3
two springs
limit switch
(S101)
OPTICAL PICK-UP (KSS-213D/Q-NP), SLED MOTOR (M102), SPINDLE MOTOR (M101)
1
claw
2
sled shaft
3
optical pick-up (KSS-213D/Q-NP)
3
two springs
4
two screws
(P 2
×
3)
5
sled motor
(M102)
6
spindle motor
(M101)
